Thermostat advice

Discussion in 'Land Rover Freelander' started by Cockney john, Apr 23, 2019.

< Previous Thread | Next Thread >
  1. Cockney john

    Cockney john New Member

    Joined:
    Sep 19, 2018
    Posts:
    9
    Likes Received:
    1
    Location:
    Shebbear devon
    Hi I've got a 2.5 v6 freelander 1is there any manual to tell me how to change the thermostat as the only manuals say not for v6 any help would be appreciated

  2. Old diver

    Old diver Well-Known Member

    Joined:
    May 29, 2016
    Posts:
    372
    Likes Received:
    150
    Location:
    Dunfermline, Fife
    Have you considered putting a back up thermostat in the top hose. It is a recognised fix and is so easy to do. It is well documented on here with plenty of good pics. I did it recently and it works great.

  3. Nodge68

    Nodge68 Well-Known Member

    Joined:
    Nov 15, 2011
    Posts:
    17,290
    Likes Received:
    3,328
    Location:
    Near Newquay
    Not on the V6.:eek:
    It'll overheat and pop it's head gaskets.

  4. Nodge68

    Nodge68 Well-Known Member

    Joined:
    Nov 15, 2011
    Posts:
    17,290
    Likes Received:
    3,328
    Location:
    Near Newquay
    Why do you need to change the thermostat?

    Rave will have the necessary information.

    It's a 4 hour job, more if you need to extract it from the block and make good any sealing faces.

    It's possible to do DIY, but you need to know the KV6 well, or strip the engine down methodically, labelling every wire and pipe.

  5. Rich in Vancouver

    Rich in Vancouver Well-Known Member

    Joined:
    May 15, 2016
    Posts:
    395
    Likes Received:
    190
    Location:
    Near Vancouver Canada
  6. Cockney john

    Cockney john New Member

    Joined:
    Sep 19, 2018
    Posts:
    9
    Likes Received:
    1
    Location:
    Shebbear devon
    Hi I'm new to all this but my fan looks like it's been rewired and runs 90 % of the time and its bloody loud someone said it's probably because the thermast isn't working so they make the fan run more

  7. kermit_rr

    kermit_rr Well-Known Member

    Joined:
    Dec 9, 2018
    Posts:
    1,957
    Likes Received:
    906
    Location:
    North Shropshire
    Thermostats usually fail in the open position, in which case it would run cold. If it failed in the closed position then it would overheat. Regardless how long the fan operated.
    What does the dash say?

  8. Nodge68

    Nodge68 Well-Known Member

    Joined:
    Nov 15, 2011
    Posts:
    17,290
    Likes Received:
    3,328
    Location:
    Near Newquay
    How do you know the fan has been rewired? It's speed is controlled by the engine ECU, so isn't easy to mess with, unless the control unit has been bypassed.

    If the engine is running hot, then the fan will run more than it should, but you need to check the engine temperature on the OBD2 live data to prove actual engine temperature.

    In my experience, the cooling fans of the KV6 do run quite a lot. The engine makes lots of heat, as does the gearbox. This heat is removed by the radiator, assisted by the fans.
    Not on the KV6. The wax capsule normally leaks its wax, preventing the thermostat from opening. ;)

  9. Nodge68

    Nodge68 Well-Known Member

    Joined:
    Nov 15, 2011
    Posts:
    17,290
    Likes Received:
    3,328
    Location:
    Near Newquay
    The dash gauge is stabilised, so shows normal when the engine is between 75°C and 115°C.

  10. Cockney john

    Cockney john New Member

    Joined:
    Sep 19, 2018
    Posts:
    9
    Likes Received:
    1
    Location:
    Shebbear devon
    It seems I have a lot to learn you're all so helpful thanks for all the advice. I obviously need someone close to get lessons from

  11. Nodge68

    Nodge68 Well-Known Member

    Joined:
    Nov 15, 2011
    Posts:
    17,290
    Likes Received:
    3,328
    Location:
    Near Newquay
    The KV6 Freelander can be a mine field to look after.

    But if you want to learn, or want someone who knows them to take a look, then I'm in Cornwall. ;)

  12. Cockney john

    Cockney john New Member

    Joined:
    Sep 19, 2018
    Posts:
    9
    Likes Received:
    1
    Location:
    Shebbear devon
    Hi mate where in Cornwall are you

  13. bukko

    bukko Well-Known Member

    Joined:
    Jul 22, 2011
    Posts:
    1,205
    Likes Received:
    30
    Location:
    Lake Somerset (but I'm a Landanna)

  14. Cockney john

    Cockney john New Member

    Joined:
    Sep 19, 2018
    Posts:
    9
    Likes Received:
    1
    Location:
    Shebbear devon
    bukko likes this.
  15. Rich in Vancouver

    Rich in Vancouver Well-Known Member

    Joined:
    May 15, 2016
    Posts:
    395
    Likes Received:
    190
    Location:
    Near Vancouver Canada
    That's a side-effect of owning a V6 Freelander!
