Series 3 suspension lift (diff angle issues)

You can do it, it's a right fag, it'll trash your props, yer motor will handle like crap, you'll gain nothing from it & it'll look ridiculous! Other than that, it's a great idea.

Save yer pennines & buy some 235/85's on 16" rims, even a secondhand set with some tread left. They'll fill your wheel arches better & actually lift your diffs & give more ground clearance.

Springs over axle on a landy not only looks ridiculous but it'll probably kill yer into the bargain

ear can you actually GET lift kits fer a series? does it just mean changing it from leaves to coils?

cheapest option - just drive over smaller obsticles!! sorted!!

Or get some extended shackles from a EX MOD 109? And fit 7.50s. Im sure that'll be high enough!

TheVengefulElephant said:

ear can you actually GET lift kits fer a series? does it just mean changing it from leaves to coils?

Click to expand...

yeh like matt said , extended shackles ... but my opinion will always be , thus , unless you asbolutly need to lift it then dont bother cos it aint worth the hassle . just put new good quality springs and shockers on it with some decent tyres and it'll take you where you wonna go .... you'd be suprised what a well sorted series will do .

god made it the way it is , armys alover the world seemed to think they were ok . just my opinion and its up to you ....

lrb2 said:

yeh like matt said , extended shackles ... but my opinion will always be , thus , unless you asbolutly need to lift it then dont bother cos it aint worth the hassle . just put new good quality springs and shockers on it with some decent tyres and it'll take you where you wonna go .... you'd be suprised what a well sorted series will do .

god made it the way it is , armys alover the world seemed to think they were ok . just my opinion and its up to you ....

Click to expand...

No I think you're right, I'm just toying with the idea of properly kitting out an 80 for some serious offroad.

I've fitted 1 ton shackles, gives a useful lift at both ends for £30.
Also fitted 9.00x16 tyres, gives huge lift, but some bodywork mods required.
I now have 13" clearance under the diffs.

Spyderman said:

I've fitted 1 ton shackles, gives a useful lift at both ends for £30.
Also fitted 9.00x16 tyres, gives huge lift, but some bodywork mods required.
I now have 13" clearance under the diffs.

Click to expand...

jesus that looks good , never seen a shorty on 900's before .... nice ..

lrb2, there ain't much that'll stop it.

hows your gearing tho ?? , quite high i would have thought ...

Gearing isn't too bad, I just use low 2nd, where i used to use low 3rd. Cruises on motorway like it's got an overdrive. Acceleration was a problem from standstill, but I'm fitting a 2.5 N/A now, so hopefully a bit more oomph will overcome that. Biggest problem is downhill in low 1st is a bit quick, but I'm pretty fearless so that doesn't worry me. Ultimately a 1 ton or 101 Transfer Box would be the answer, but they're as rare as rocking horse ****.

Hmmm from that pic above you have your shackle conected to your front panel.. Hope you dont tow from it!

still it does look good ....

matt-unsworth said:

Hmmm from that pic above you have your shackle conected to your front panel.. Hope you dont tow from it!

Click to expand...

storage i would have thought matt , i doubt he'll use that for towing ...

lrb2 said:

storage i would have thought matt , i doubt he'll use that for towing ...

Click to expand...

Absolutely right. Just somewhere to attach the towing bridle, to stop it dangling in the way when not in use. Taking it off-on all of the time when it's covered in mud was destroying the inside, so I put it on before laning and remove it after it's been washed.

kinell spyder. that's mad! Definately going on the list.

Just need 2 fields instead of 1 to turn around.....

Does look the D.. D......

The steering really was hardly affected. Only had to adjust the steering stops a tiny bit, so it's still only 1 field to turn around.
