my queustion is does anyonone have awiring diagram of td5 main loom plugs up to instrument binnacle , I have the ultra rare conversion loom, but want all my mods to be hidden seemlessly, it seem odd but as a full time Carer I dont really have time to figure out what poss has already been done, please

Dippypud · Nov 29, 2020

Chillidogs63 said:
my queustion is does anyonone have awiring diagram of td5 main loom plugs up to instrument binnacle , I have the ultra rare conversion loom, but want all my mods to be hidden seemlessly, it seem odd but as a full time Carer I dont really have time to figure out what poss has already been done, please

Put your question up in the relevant section for your vehicle, it'll be seen by more peeps ...

Which of yours is the TD5, the 90 or the 110 ?

https://www.landyzone.co.uk/forum/defender-90-110-130.7/

saxavordian · Nov 29, 2020

Welcome to the zoo fellow carer.

brianp38dse · Nov 29, 2020

Hello and welcome

David Leech · Nov 29, 2020

Is this any good?.....

http://www.super7thheaven.co.uk/wp-content/uploads/2016/08/Defender-MY2002-Wiring-Diagram.pdf

Hippo · Dec 5, 2020

Welcome to the forum

Chillidogs63 · Dec 6, 2020

Thank you, made me smile

Chillidogs63 · Dec 6, 2020

Its a help, thank you, mine has an ultra late 300tdi loom on the bulkhead, that allowed me to just plug in all rear lights and a later tow bar loom, 13pin, only had to run a 60 amp supply to rge rear for the relays that came with the kit...
