Proper DRLs are only supposed to illuminate once the vehicle has started moving forward, normally extinguishing when the handbrake is applied. However this is quite difficult to achieve on the FL1, without some monitoring of the PWM speed signal.

There is an engine running signal at the CCU, which will allow DRLs to only operate while the engine is running. There's another engine running signal at the front bumper of the TD4 FL1.

Looks nice.

Z2

Z3

Nodge68 said:

That's a neat solution.

Proper DRLs are only supposed to illuminate once the vehicle has started moving forward, normally extinguishing when the handbrake is applied. However this is quite difficult to achieve on the FL1, without some monitoring of the PWM speed signal.

There is an engine running signal at the CCU, which will allow DRLs to only operate while the engine is running. There's another engine running signal at the front bumper of the TD4 FL1.

Click to expand...

Is road speed one of the items of data in the ODBII diags?

Would need some micro-electronics like an Arduino to talk to it to determine if the car is moving but probably the easiest option if speed can be read through ODB.

What the ODB diags won't say though is whether the indicators are on. Didn't you say a while back that the DRLs have to extinguish if the indicators are flashing?

GrumpyGel said:

Is road speed one of the items of data in the ODBII diags?

Click to expand...

The speed signal comes from the ABS ECU on post A1 chassis number vehicles. I'm not sure about the earlier pre-A1 Freelander, as the earlier system was pretty much replaced after the 2001 update.

The speed signal is used for the speedometer, and for the variable volume control on the FL1 stereo, after the facelift FL1 came out.

Z4

GrumpyGel said:

Didn't you say a while back that the DRLs have to extinguish if the indicators are flashing?

Click to expand...

Only if the DRL is in the same light lens as the indicator, or is within a certain distance between the two lights.
