'03MY L322 Petrol 114k5 miles

Discussion in 'Range Rover' started by RichardSEL, Jan 4, 2019.

< Previous Thread | Next Thread >
  1. Saint.V8

    Saint.V8 Dyed-in-the-wool 100% RR Junkie

    Joined:
    Apr 27, 2008
    Posts:
    16,298
    Likes Received:
    2,079
    Location:
    Wiltshire - Nadder valley - its rather pretty
    I think you need to download RAVE and read through the vehicle handbooks, system operation and descriptions i nthe Workshop manuals - then you will be uber informed.....

    Oh, and the smooth talker is yours truly :D:D:D

  2. Saint.V8

    Saint.V8 Dyed-in-the-wool 100% RR Junkie

    Joined:
    Apr 27, 2008
    Posts:
    16,298
    Likes Received:
    2,079
    Location:
    Wiltshire - Nadder valley - its rather pretty
    OK.....can you refresh the brain as I am getting different messaages here..... on some posts you say the key won't go past pos 1.....but you don't get radio displayed etc - at pos 1 you should get this...in other posts you say it won't turn anything on....

    in another post you say the display just showed dashes and not the time or the date.....and in one just a moment past, you say you can get to the Aux Heat function on the display....you won't get this unless you can get the key to pos 1.....

    So, refresh the brain.....

    Can you get the key to position 1 to bring the radio/sat nav/OBC on? or is it not turning at past a few degrees and nothing comes on at all?

  3. Henry_b

    Henry_b Rover V8 Powered

    Joined:
    Jan 29, 2018
    Posts:
    10,648
    Likes Received:
    8,718
    Location:
    Hereford****e
  4. backinblack

    backinblack Well-Known Member

    Joined:
    Jan 30, 2015
    Posts:
    1,357
    Likes Received:
    755
    Location:
    North Manchester
    Ok so checked my gear lever on way home, don't need brake pressed to move out of park, only N to D.
    From what i've read on here FBH was an option on the petrol so you may or may not have it. Of course there are lots of other things as well.
    As I say I am a newbie to the L322 also.

  5. Saint.V8

    Saint.V8 Dyed-in-the-wool 100% RR Junkie

    Joined:
    Apr 27, 2008
    Posts:
    16,298
    Likes Received:
    2,079
    Location:
    Wiltshire - Nadder valley - its rather pretty
    errrr......from the handbook....


  6. backinblack

    backinblack Well-Known Member

    Joined:
    Jan 30, 2015
    Posts:
    1,357
    Likes Received:
    755
    Location:
    North Manchester
    I only checked without engine running.

  7. RichardSEL

    RichardSEL Active Member

    Joined:
    Jan 3, 2019
    Posts:
    235
    Likes Received:
    48
    Location:
    Blackheath
    Yes, every time I'm trying things I have my foot on the brake

    Thanks for bothering to reply and post that pic -- I must find myself another pic file sharing site so I can post pics of what I'm seeing here. How did you disconnect your FBH? Pulling the plugs or a fuse somewheres?

    Last edited: Jan 12, 2019
  8. RichardSEL

    RichardSEL Active Member

    Joined:
    Jan 3, 2019
    Posts:
    235
    Likes Received:
    48
    Location:
    Blackheath
    OK

    Yes. That's the current scene

    Yes, on manual unlock (driver's door only unlocks) and climbing in the internal cabin lights come on and the headunit's Land Rover screen is shown

    I still get that but eventually, the headunit's Land Rover screen (where at the bottom I get --/--/2019) switches off and the internal lights go out. That's irrespective of whether the key's at position 1 (is that the same as what's referred to as 10º?) or not

    The action of moving the key to position 1 does not change anything. I only now move it to position 1 (a) in hope it'll move beyond that, and (b) to try and go into retrain mode for less than 5 seconds before removing the key, press and holding in the unlock button, pressing the lock button three times in sucession and then releasing both.
    Unlock LED then flashes 10 times. When I'd retrained before (believing this also permitted IGN) the door locks would lock and then unlock. And all the windows went down. The last time I tried this the windows just went down about 1" and are now stuck like that. I had no door lock operation.

    That's as it is now on the bottom of the Land Rover screen before that screen shuts off

    That was when everything was working AOK -- I still don't know whether I've inadvertently enabled FBH by that screen. Before I put all zeroes in the times it was just showing hyphens in the times

    It's not position 1 that brings the head unit on. Position 1 doesn't change anything. When the Land Rover opening screen is showing, no amount of pressing either of the two buttons will bring the radio on nor the OBC screen. The only thing that will operate is the open front panel button that just exposes the cassette tray. Press the button again and it shuts. Or shuts by itself after some pre-determined time

    The key moves into position 1 and won't move any further.

    Last edited: Jan 12, 2019
  9. RichardSEL

    RichardSEL Active Member

    Joined:
    Jan 3, 2019
    Posts:
    235
    Likes Received:
    48
    Location:
    Blackheath
    Sorry, I can't find this "steering lock fuse" you refer to. The only fuse chart I have is for behind glove box.
    The chart for there gives F20 30A Drivers seat & steering column; and F23 15A Steering column. There are three fuses listed for Central locking also

  10. Saint.V8

    Saint.V8 Dyed-in-the-wool 100% RR Junkie

    Joined:
    Apr 27, 2008
    Posts:
    16,298
    Likes Received:
    2,079
    Location:
    Wiltshire - Nadder valley - its rather pretty
    OK, one fact has been established - you are NOT turning the key to pos 1......

    The fact that the screen comes on when you unlock or open a door is just the Sat Nav unit going through its start up sequence, it will then shutoff after a couple of minutes if it doesn't get a wake signal from the ignition switch at position one or above.

    So the small movement you are able to make is indeed the 10deg 'wake the transponder coil' movement and not position 1 as you don't wake the radio up and be able to listen to it!

    Now it could be a few things, Transponder in the key is lost/not working (small plastic piece that is loose in the key), Induction coil around ignition switch is duff and is not picking up the key.....

    Now I have heard issues with the steering lock ECU and/or the internal lock solenoid failing can prevent the ignition switch and steering lock from disengaging.....you'll need to research this and see if it is a potential issue - loads of it on the web.

    So, not being able to get the key to pos 1 means the ignition switch and steering lock are not disengaging.

    I have a cut key without electronics and I am sure I can use this key in the switch, turn it to the 10deg position and back, then turn it all the way to wake the car up - obviously it won't start the car as it doesn't have any electronics in the key......but i am sure I can use it to turn the ignition on - I will have to check later......

    If it is the case that I can indeed turn the key to get the ignition on (but not start the car) then it proves that even if the EWS doesn't get a signal from the key, you should still be able to turn the ignition on......but I will have to check this later when I go out.

    Last edited: Jan 12, 2019
  11. Saint.V8

    Saint.V8 Dyed-in-the-wool 100% RR Junkie

    Joined:
    Apr 27, 2008
    Posts:
    16,298
    Likes Received:
    2,079
    Location:
    Wiltshire - Nadder valley - its rather pretty
    I think it is fuse 18......there are those who have steering lock ECU issues who have made a bypass with a toggle switch for this fuse and they toggle the switch off then on, to reset the ECU and that gives them one turn of the key......again google this as I have read this before.

  12. Disco1BFG

    Disco1BFG Well-Known Member

    Joined:
    Mar 18, 2015
    Posts:
    5,043
    Likes Received:
    2,521
    Location:
    Buxton
    You can upload the pics direct to the forum - "upload a file" - middle button in the reply to post "box" .....

    Much better IMHO, as they don't disappear into the ether when botophuckit spit their dummy out again

    tomcat59alan likes this.
  13. RichardSEL

    RichardSEL Active Member

    Joined:
    Jan 3, 2019
    Posts:
    235
    Likes Received:
    48
    Location:
    Blackheath
    Yes, Fuse 18 is listed in the handbook as 10A (red) Immoboliser. And there's mentions of it on t'interwebnet

    Have just been out and placed the old Varta Blue (now fully charged) in parallel with the new Yuasa installed.
    Totally disconnected the Varta was showing 12.87V. Immediately I connected it in parallel with the installed new Yuasa that dropped by ½V. So there's definately some load causing volts drop when measured. Course that's not in "sleep" mode. Bought the Yuasa in as it's only showing 12.2V off load. It's taking charge currently (geddit?!) at 3½A

    Cleaned the terminals that were oxidised on the posts and clamps. The -ve should've been tighter IMO

    Last edited: Jan 12, 2019
  14. RichardSEL

    RichardSEL Active Member

    Joined:
    Jan 3, 2019
    Posts:
    235
    Likes Received:
    48
    Location:
    Blackheath
    Yes, just done that this morning. The -ve could've been tighter IMO

    That's progress! That lever allowed me to move the gear lever into Neutral. So at least I can use an ordinary low loader without the need for those plastic shoes to slide the car about. Grateful for that ;)

    Yes, and there's definately a load being applied even when key's not in ignition. The volts drop by about ½V when connected

    Last edited: Jan 12, 2019
  15. backinblack

    backinblack Well-Known Member

    Joined:
    Jan 30, 2015
    Posts:
    1,357
    Likes Received:
    755
    Location:
    North Manchester
    FBH fuse 59 on my Diesel. Looks like you have bigger issues than this though.

  16. RichardSEL

    RichardSEL Active Member

    Joined:
    Jan 3, 2019
    Posts:
    235
    Likes Received:
    48
    Location:
    Blackheath
    Right, I now know the difference -- the key's just going to 10º and no further

    When I opened up the key that didn't work to see what battery it was (CR2016) I didn't see see any small plastic piece in the key that was loose. I'll open it up again to check. -- no nothing. There is a plastic piece that looks as if its mold-fitted into the plastic body. It's got the Siemens number on it

    Quite possibly, although then that'd mean it was just co-incidence that this unable to move beyond the 10º started soon after I changed car battery

    Last edited: Jan 12, 2019
  17. RichardSEL

    RichardSEL Active Member

    Joined:
    Jan 3, 2019
    Posts:
    235
    Likes Received:
    48
    Location:
    Blackheath
    Seems from your pic I haven't got an FBH -- one less thing to worry about!

  18. RichardSEL

    RichardSEL Active Member

    Joined:
    Jan 3, 2019
    Posts:
    235
    Likes Received:
    48
    Location:
    Blackheath
    So found Fuse 18, removed it, did dance to the rain gods around RR, noted rustling of the lace in neighbours' windows, replaced fuse -- was still in neutral and... er... still 10º max turn. Which is unfortunate...

    Last edited: Jan 12, 2019
  19. gold rover

    gold rover Well-Known Member

    Joined:
    Nov 22, 2010
    Posts:
    7,178
    Likes Received:
    4,353
    Location:
    Scotland,
    I'm running out of popcorn :( Anyone got sharesies, maybe? Oh and a drink too please


    @Henry_b

    Last edited: Jan 12, 2019
    Henry_b and Saint.V8 like this.
  20. Henry_b

    Henry_b Rover V8 Powered

    Joined:
    Jan 29, 2018
    Posts:
    10,648
    Likes Received:
    8,718
    Location:
    Hereford****e
    gold rover likes this.
