Which door seal for new series door pillar with no lip

Discussion in 'Series Land Rovers' started by scottonthefen, Apr 27, 2020.

< Previous Thread | Next Thread >
  1. scottonthefen

    scottonthefen Well-Known Member

    Joined:
    Jul 31, 2017
    Posts:
    512
    Likes Received:
    158
    Location:
    England
    I'm replacing the old door pillar on my 2A 88", which has a lip for the door seal to sit against, with a new pillar that doesn't have that lip. I assume I can't get a new pillar with that lip but if I can it's not too late to switch so let me know if that's the case. If I do have to fit a pilar with no lip for the seal I understand I need to fit the newer type of seal as used on those hi-tech Defender ve-hicles. Is that right, or will a series style seal fit?

  2. Rodeo Joe

    Rodeo Joe Well-Known Member

    Joined:
    Dec 30, 2017
    Posts:
    1,578
    Likes Received:
    704
    Location:
    norfolk
    I don't see why a series seal wouldn't fit, they rivet on. The problems arise when you want to put the newer one piece seal onto the lipped type cos you either have to hit it with a mallet or cut the lip off.......guess which I did:rolleyes:

    scottonthefen likes this.
  3. Bobsticle

    Bobsticle De Villes Advocaat

    Joined:
    Aug 8, 2013
    Posts:
    17,262
    Likes Received:
    19,215
    Location:
    Manchester
    Do yourself a favour and remove the lip. Fit a modern knock on seal and enjoy the dry windless drive.
    Plenty about if you look on eBay. They are pre mitred at 90 degrees for the top corner of the door opening then it’s just a case of running them around the frame.

    Oh, little tip; fill the joint between the van side and tub as it meets the door frame. It’s only a small gap just above the striker plate but park on a hill nose down and rain pours in. Prolly better using a squidge of panel joint seal.

    Last edited: Apr 28, 2020
  4. scottonthefen

    scottonthefen Well-Known Member

    Joined:
    Jul 31, 2017
    Posts:
    512
    Likes Received:
    158
    Location:
    England
    There’s no lip on my new pillar so I’d like to use a knock on seal as I’ve heard they’re better. But what do I look for? Do I buy a door seal to fit a defender, or is it called something else? I’ve looked for clip on and knock on seal and so on but see loads of different options. ?

  5. Rodeo Joe

    Rodeo Joe Well-Known Member

    Joined:
    Dec 30, 2017
    Posts:
    1,578
    Likes Received:
    704
    Location:
    norfolk
    I used some old discovery seals on mine but then I'm not too precious about it .....but I am dry:D

  6. scottonthefen

    scottonthefen Well-Known Member

    Joined:
    Jul 31, 2017
    Posts:
    512
    Likes Received:
    158
    Location:
    England
    I've seen a lot of advice to buy official parts because the britpart seals and so on are useless. Some of the original seals I've seen are £20-30 so I really don't want to buy something that doesn't fit. :D I've never fit a seal in my life so I don't know how interchangeable they are or how likely something I buy is to not fit at all. probably over-thinking it as usual :D

  7. Rodeo Joe

    Rodeo Joe Well-Known Member

    Joined:
    Dec 30, 2017
    Posts:
    1,578
    Likes Received:
    704
    Location:
    norfolk
    If you grind off the lip you can fit any seal really as long as it lets the door shut, it will involve a bit of trimming and a pair of tin snips is handy to mitre the corners and cut around the striker plate for the door catch.
    See if you can get an old one from somebody and have a go then you can decide if its worth the expense getting new ones (I've already decided). If you cut the lip off it doesn't really stop you putting series type seals back on later.

    scottonthefen likes this.
  8. Dippypud

    Dippypud Never Knowingly Understood

    Joined:
    May 2, 2011
    Posts:
    55,867
    Likes Received:
    30,898
    Location:
    The Wooly Witch
  9. dag019

    dag019 Well-Known Member

    Joined:
    May 18, 2014
    Posts:
    3,157
    Likes Received:
    1,266
    Location:
    Warwick
    Now that is just not true! They may be better than the series version but they are not that good, it still remains a land rover. :rolleyes:

  10. Bobsticle

    Bobsticle De Villes Advocaat

    Joined:
    Aug 8, 2013
    Posts:
    17,262
    Likes Received:
    19,215
    Location:
    Manchester
    I have no issues with my doors. ;)

  11. scottonthefen

    scottonthefen Well-Known Member

    Joined:
    Jul 31, 2017
    Posts:
    512
    Likes Received:
    158
    Location:
    England
    I like how I'm fixating on the door seal when I've still got to replace the door pillar and bulkhead corner. Having never done it before.. :confused::D

    Rodeo Joe and Bobsticle like this.
  12. Bobsticle

    Bobsticle De Villes Advocaat

    Joined:
    Aug 8, 2013
    Posts:
    17,262
    Likes Received:
    19,215
    Location:
    Manchester
    It’s called a series door upgrade door seal. For a reason.
    The only downside is they are one piece so if you fancy invading central Africa one Sunday afternoon it’s a pain taking the roof off.


    scottonthefen likes this.
  13. dag019

    dag019 Well-Known Member

    Joined:
    May 18, 2014
    Posts:
    3,157
    Likes Received:
    1,266
    Location:
    Warwick
    If you are taking the roof off you may as well take the door tops off, and at that point you no longer need door seals so you take them off as well!

  14. Bobsticle

    Bobsticle De Villes Advocaat

    Joined:
    Aug 8, 2013
    Posts:
    17,262
    Likes Received:
    19,215
    Location:
    Manchester
    Yes but as one piece the door bottoms will be without anorl. You wouldnt want a draught just coz the roofs off. :p:p:D
