Track rod
- Thread starter Dopey
- Start date
This site contains affiliate links for which LandyZone may be compensated if you make a purchase.
Anaconda
Well-Known Member
- Posts
- 2,006
- Location
- Thames Valley
Or on the S2club forum. I set the length straight ahead using an adjustable mop handle on the S2a. With wheels straight ahead centre the steering box and adjust drag link to fir, would that work?
I presume you had to buy a modified kit of some sort, any set up instructions?
I presume you had to buy a modified kit of some sort, any set up instructions?
- Posts
- 31,476
- Location
- North Shropshire
Toe in on an standard series is 1.2-2.4mm
Anaconda
Well-Known Member
- Posts
- 2,006
- Location
- Thames Valley
1157 to 1160 measured between ball joint centres.
Taken from Series 3 workshop manual.
Taken from Series 3 workshop manual.
Last edited:
- Posts
- 31,476
- Location
- North Shropshire
Close.. when I've done it in the past, I've measured at the rim. It's further from the pivot point so more accurate
