L322 Suspension problem after jacking front end. SOLVED

Discussion in 'Range Rover' started by dannybhardy, Nov 9, 2018 at 4:05 PM.

< Previous Thread | Next Thread >
  1. dannybhardy

    dannybhardy Member

    Joined:
    Friday
    Posts:
    20
    Likes Received:
    4
    Location:
    Northwest UK
    Had a mobile mechanic out during the week to change the cv joint on my 2003 vogue.

    When ive returned from work today (I work away) the back end is sitting high, whereas the front is sitting low and the passenger side (which was the side which was jacked up) is sitting on the bump stops!

    Now I need the car to get to and from work as the missus said this was the only week she would take me in, so need to get it sorted!

    Any ideas?

    Dan :)

  2. marjon

    marjon Well-Known Member

    Joined:
    Jul 15, 2018
    Posts:
    387
    Likes Received:
    254
    Location:
    Bulgaria
    Have you actually taken the time first to introduce yourself in the correct section.

    Have you actually tried to start the car to see if it sorts it’s life out? They do most of the time.

    Welcome.

    J.

  3. dannybhardy

    dannybhardy Member

    Joined:
    Friday
    Posts:
    20
    Likes Received:
    4
    Location:
    Northwest UK
    Yes I have started the car, its going up and down slowly at the back when I try and raise/lower the suspension, but nothing on the front properly.

    I think it needs the level sensor resetting somehow?

  4. Saint.V8

    Saint.V8 Dyed-in-the-wool 100% RR Junkie

    Joined:
    Apr 27, 2008
    Posts:
    15,284
    Likes Received:
    1,415
    Location:
    Surrey - Near the middle, close to some green bits
    Have you run the engine with the door open for ten minutes, to ensure the air tank is full.....??

    Do you have any fault messages on the dash, lights on or off on the height selector switch ?? etc etc...

    They don't like have dangling legs....and if the mech didn't disconnect the height sensor link arm before the work, he could have damaged the sensor, but a fault should be shown for that and Air Susp. Disabled message on the daash.

  5. dannybhardy

    dannybhardy Member

    Joined:
    Friday
    Posts:
    20
    Likes Received:
    4
    Location:
    Northwest UK
    Nope, no error messages on the dash (had the air susp inactive the other week because the battery voltage was low).

    Havent tried with the door open for 10 mins yet. Ive no lights on the up/down switch and when I move the switch for raise or lower it flashes the corresponding indicator light, even if it doesn't do what its supposed to fully.

  6. marjon

    marjon Well-Known Member

    Joined:
    Jul 15, 2018
    Posts:
    387
    Likes Received:
    254
    Location:
    Bulgaria
    You need to have patience and as saint said leave door open and go make a cup of tea
    They used to have a funny wheel off ground thing too and it can get all screwey.
    I had a recovery driver disconnect my battery before disconnecting the trailer once,so the arse End went up,it sorted it’s life out later.

    EAS system sounds weak maybe.

    J.

  7. dannybhardy

    dannybhardy Member

    Joined:
    Friday
    Posts:
    20
    Likes Received:
    4
    Location:
    Northwest UK
    Air suspension was fine the week before when I took it to a garage. They said it was all hunky dory :(

  8. dannybhardy

    dannybhardy Member

    Joined:
    Friday
    Posts:
    20
    Likes Received:
    4
    Location:
    Northwest UK
    OK, an update.

    Spent 30 mins outside with the door open and the engine running. Nothing, so I thought I would take it round the block and see if it reset itself. Nothing other than now I have the Air Susp Inactive error and no lights on the suspension control panel. not even the indicator light.

  9. Saint.V8

    Saint.V8 Dyed-in-the-wool 100% RR Junkie

    Joined:
    Apr 27, 2008
    Posts:
    15,284
    Likes Received:
    1,415
    Location:
    Surrey - Near the middle, close to some green bits
    Then I would say the next thing to do is plug it into diagnostics and see what the ECU thinks the fault is.

    It could be a weak compressor, leaking air bladder or a dud sensor - diagnostics first.

  10. dannybhardy

    dannybhardy Member

    Joined:
    Friday
    Posts:
    20
    Likes Received:
    4
    Location:
    Northwest UK
    Ok, going to have to see what I can do :( after shelling out for the cv joint to be replaced funds are tight lol.

    Can anyone recommend a cheap option?

  11. pete12345

    pete12345 Active Member

    Joined:
    Jun 15, 2012
    Posts:
    729
    Likes Received:
    48
    Location:
    Isle Sheppy
    Cheap option L322

  12. dannybhardy

    dannybhardy Member

    Joined:
    Friday
    Posts:
    20
    Likes Received:
    4
    Location:
    Northwest UK
    Well it were fine before it was jacked up lol, so I am hoping its not an actual fault and just needs a reset :)

  13. tarphenry

    tarphenry Well-Known Member

    Joined:
    Oct 6, 2014
    Posts:
    1,084
    Likes Received:
    225
    Location:
    bury lancs
    The trouble is you dont know what to fix if you dont know whats broken! get it on diagnostics , then all who know, on here, will help you

  14. myfirstl322

    myfirstl322 Well-Known Member

    Joined:
    Dec 29, 2012
    Posts:
    7,481
    Likes Received:
    1,971
    Location:
    Geroutavit.....
    You need to stop being a ****.

    Who made you prefect?

    Leave that crap for the likes of Goldie and her pet gimp Henry.

  15. dannybhardy

    dannybhardy Member

    Joined:
    Friday
    Posts:
    20
    Likes Received:
    4
    Location:
    Northwest UK
    And yes I did introduce myself in the right area.

    marjon and myfirstl322 like this.
  16. Saint.V8

    Saint.V8 Dyed-in-the-wool 100% RR Junkie

    Joined:
    Apr 27, 2008
    Posts:
    15,284
    Likes Received:
    1,415
    Location:
    Surrey - Near the middle, close to some green bits
    How about contacting the mech and explaining the situation and that you would like him to sort it, as it worked before he got his mits on it, and now it doesn't work.

    If he is anywhere near knowledgeable on the L322 - he will have diagnostic gear to assist.

    Gunnerhavesome likes this.
  17. myfirstl322

    myfirstl322 Well-Known Member

    Joined:
    Dec 29, 2012
    Posts:
    7,481
    Likes Received:
    1,971
    Location:
    Geroutavit.....
    This forum is becoming awash with self appointed monitors.

    The worst is the incessant garbage spouting newbies who write every last word that they actually think, on every subject.

    Boils my **ss.

  18. philip pickard

    philip pickard Active Member

    Joined:
    Jan 20, 2016
    Posts:
    199
    Likes Received:
    15
    Location:
    doncaster
    sounds like a dodgy height sensor on passenger side. it could be stuck. look to see if its still connected right. spray some wd40 on it. may work may not.

  19. ukadamwest

    ukadamwest Well-Known Member

    Joined:
    Feb 28, 2012
    Posts:
    2,251
    Likes Received:
    401
    Location:
    Surrey
    dumbass question but have you tried jacking the dropped corner up to the correct height with the engine running and the air tank full ?

  20. gold rover

    gold rover Well-Known Member

    Joined:
    Nov 22, 2010
    Posts:
    3,999
    Likes Received:
    1,726
    Location:
    Scotland,
    tenor (8).gif

    Gunnerhavesome likes this.
