power steering pump replacement

Discussion in 'Land Rover Discovery' started by big john 53, Jun 15, 2011.

< Previous Thread | Next Thread >
  1. big john 53

    big john 53 New Member

    Joined:
    Feb 19, 2008
    Posts:
    15
    Likes Received:
    0
    The power steering pump has packed in on my 300tdi

    I am having trouble removing the viscose fan are there any tips

  2. jamesmartin

    jamesmartin Well-Known Member

    Joined:
    Dec 8, 2010
    Posts:
    81,699
    Likes Received:
    11,860
    Location:
    louth lincs
    first off its lh thread and shock it undone with hammer on spanner handle rather than pull,if that dont work get large punch and hit nut then retry

  3. Brian S

    Brian S Well-Known Member

    Joined:
    Nov 8, 2008
    Posts:
    2,886
    Likes Received:
    0
    Location:
    Braintree, Essex
    Where are you?

    I presume you have the correct Viscous Fan removal spanner? Not really easy without it, perhaps someone near you would have one to lend you.

    Mine cost me £12 from Halfords and after its single use sits in my toolbox.

    Oh and remember its reverse thread. I know its already been said on here, but worth repeating. I knew it and still wasted a good 10 minutes trying to turn it the conventional way only to give up that evening, then in the morning remember and take a few seconds to undo it.... :lol:

  4. shocker

    shocker Well-Known Member

    Joined:
    Jun 26, 2008
    Posts:
    2,038
    Likes Received:
    35
    Location:
    BODMIN MOOR,KERNOW
    Why do you need to take the fan off to replace the PAS pump ?

  5. halo

    halo Active Member

    Joined:
    Aug 16, 2006
    Posts:
    660
    Likes Received:
    0
    Location:
    derbyshire
    i was gonna say the same thing :confused:

  6. shocker

    shocker Well-Known Member

    Joined:
    Jun 26, 2008
    Posts:
    2,038
    Likes Received:
    35
    Location:
    BODMIN MOOR,KERNOW
    Beatcha to it !:D:D:D

  7. big john 53

    big john 53 New Member

    Joined:
    Feb 19, 2008
    Posts:
    15
    Likes Received:
    0
    borrowed a spanner to remove the fan came off no problem
    removed the power steering pump reassembled and run the engine up too temperature when removing the trapped air I turned the bolt the plastic one top of the thermostat housing the bolt sheared somebody who had the Disco before me super glued it back together

  8. big john 53

    big john 53 New Member

    Joined:
    Feb 19, 2008
    Posts:
    15
    Likes Received:
    0
    why do you think
    my guess is to make thing easy for yourself and it needed to come off

  9. Pyper28

    Pyper28 Active Member

    Joined:
    Jul 22, 2008
    Posts:
    136
    Likes Received:
    0
    Location:
    Chesterfield
    For the sheared off black screw, use a rad bleed screw or a blank, PTFE tape on job done!

  10. shocker

    shocker Well-Known Member

    Joined:
    Jun 26, 2008
    Posts:
    2,038
    Likes Received:
    35
    Location:
    BODMIN MOOR,KERNOW
    Calm down mate ! It doesnt NEED to come off to change the PAS pump at all. Done the job multiple times and never needed to . If you want it out the way,thats up to you,but it doesnt NEED to come off for that reason.Just like you dont need to make posts in that tone.

  11. big john 53

    big john 53 New Member

    Joined:
    Feb 19, 2008
    Posts:
    15
    Likes Received:
    0
    I asked for advise not the nonsense you wrote with no explanation

    Anyway the job is done thanks I did it my way

  12. oldskool

    oldskool Well-Known Member

    Joined:
    Jan 29, 2010
    Posts:
    3,117
    Likes Received:
    25
    Location:
    Essex near maldon
    There's a song...................................never mind :D

  13. Myran

    Myran New Member

    Joined:
    Mar 1, 2008
    Posts:
    3
    Likes Received:
    0
    Location:
    Stockholm Sweden
    I am a professional superviser for boatengines and must react on your.......besserwisser bull****.
    I just taken out the pump of my -98 300 Tdi.
    Your posts are not only inadekvat, it is aslo rude, unpolite and does not even have the slighest guidence.
    Sorry, but I do not believe you ever done one on any late 300 Tdi unless you like to crawl on the ground and get dirty and have the oil raining on you.
    The reasons to take the fan off are, to start with, get some space and not hurt or get hurt by the fan blades.
    It is also irresponsible not to undo the fan, drain the cooling a little and pump out the oil if some left and then
    put a big can under the engine to catch she spill.
    So herefore I would say, YES it is needed to take the fan off so you can take the front cover out as well.
    To add to anyone who like to do this job clean and without acting like an ape under the car a little tip
    is that before you start the work; clean the area, especially the oil hoses and connections, The top of thu steering house to avoid dirt when later on bleeding. Also o ease the loosing of the hp oilconnection (16mm spanner) put the frame back on the pump with one of the 10mm SHORT bolts in a position so it is not in the way for the 16mm spanner. Then you can easy fit a wrench and hold the pump steady when you loose the pump.
    According to my expierence today it is very easy also to loosen the holder for the oilreservoir, loosen the hose going to the pump and let that (one "clip" halfways) hose follow the pump out. If it is clean it is a pleasure.
    Best regards from Stockholm in Sweden.

  14. Turboman

    Turboman Rural Activist

    Joined:
    Aug 21, 2010
    Posts:
    39,542
    Likes Received:
    32,301
    Location:
    Continuously Cruising
    What sort of boat engines do you supervise, then?

    gstuart likes this.
  15. gstuart

    gstuart D3 Grandad

    Joined:
    May 18, 2010
    Posts:
    23,085
    Likes Received:
    7,351
    Location:
    Swanley , Kent
    did u release that was posted 7 x years ago, lol

    Disco1BFG and Thor1950 like this.
  16. gstuart

    gstuart D3 Grandad

    Joined:
    May 18, 2010
    Posts:
    23,085
    Likes Received:
    7,351
    Location:
    Swanley , Kent

    BE83A290-D439-4D51-99B8-30FC10F76DE5.gif , snigger


    Turboman likes this.
  17. Turboman

    Turboman Rural Activist

    Joined:
    Aug 21, 2010
    Posts:
    39,542
    Likes Received:
    32,301
    Location:
    Continuously Cruising
    Thor1950 and gstuart like this.
  18. gstuart

    gstuart D3 Grandad

    Joined:
    May 18, 2010
    Posts:
    23,085
    Likes Received:
    7,351
    Location:
    Swanley , Kent
    reminded me of something my brother useto have , little steam unit

    now wheres my popcorn while we wait for the reply ref the boat engine , this will be interesting ;):D

    Thor1950 and Turboman like this.
  19. Turboman

    Turboman Rural Activist

    Joined:
    Aug 21, 2010
    Posts:
    39,542
    Likes Received:
    32,301
    Location:
    Continuously Cruising
    Used to have a Mamod steam engine when I was a kid. They are great. It wasn't in a boat, though.

  20. Turboman

    Turboman Rural Activist

    Joined:
    Aug 21, 2010
    Posts:
    39,542
    Likes Received:
    32,301
    Location:
    Continuously Cruising
    Might be a long wait, he has only posted 3 times since 2008.

    gstuart likes this.
