Injector Pump Help

K

kitkat237

Member

Posts

56

Location

Hertford

• Apr 24, 2010

• #1

hello all

i have been working really hard to try and get my series 3 landy to work properly after a fall rebuild i found out that i had the fitted the vertical cog that funs from the crankshaft was fitted 180' out witch made the engine over heat and blow that head gasket i have just changed the gasket but still cant get the engine to run with out smoke it is either white smoke or dark black depending where the pump is positioned

getting to the point i need to get hold of an injector pump Timing Gauge P/N 605863 so i can set the pump up right i have found one for £150 but that seems expensive for a tool i will only use once so dues anyone no where i could rent one or get one for a reasonable price



K

kitkat237

Member

Posts

56

Location

Hertford

• Apr 26, 2010

• #2

ok looks like i am just going to have to buy one



N

nongrokal

Active Member

Posts

184

• Apr 26, 2010

• #3

the pump has a window in the side, remover the cover plate and use a mirror to see the timing marks, these are set when the pump is made or overhauld, if the marks are a long whey out then move the timing gear a bit at a time, you may have to remove the sump to move the oil pump,



K

kitkat237

Member

Posts

56

Location

Hertford

• Apr 27, 2010

• #4

thanks for that i will look in the morning,



dr pepper

New Member

Posts

1,438

Location

lancashire

• Apr 27, 2010

• #5

From memory there are marks on the arbor as mentioned, you can advance or retard the timing a little with these, however the arbor itself is removeable seperately from the engine block, the tool photo you posted is to align the arbor.
If you only removed the pump and not the arbor then you shouldnt need that tool, unless you suspect the timing is still out.
There is an old timer method of setting the timing with a gooseneck and a dial guage that doesnt need any special tools that mi dad used to do, but I dont know how to do that.



K

kitkat237

Member

Posts

56

Location

Hertford

• Apr 27, 2010

• #6

could you let me no what position the flywheel should be in for a diesel 2.25 my pump has a DPA no. 3249F51 i think its hard to read in one of my books it says i should set it to the 13 mark on the flywheel the other says 15 ?? dose anyone no which it is many thanks for all your help
