Help my Disco 2 is down on its haunches

Discussion in 'Land Rover Discovery' started by Cromarty, Feb 7, 2020.

< Previous Thread | Next Thread >
  1. Cromarty

    Cromarty New Member

    Joined:
    Jan 6, 2020
    Posts:
    7
    Likes Received:
    0
    Location:
    72240 Saint Symphorien France
    Hi all,
    I live in rural France, my Disco 2 is my lifeline, but has just let me down, literally.......
    Came out the other day and there it was sitting on its haunches both sides down. Managed to start it up and it rose back up, and kept on rising !!!!!
    had to drive it a little way, carefully and it dropped back down, and went all the way back down.
    Tried taking the battery out and refitting and that seemed to work as it rose to correct level. Sadly by the next morning it was down again.
    I am no mechanic but i cant drive it to a garage as its miles away.
    Any ideas / help would be greatly appreciated
    Happy Friday

  2. sierrafery

    sierrafery Well-Known Member

    Joined:
    Jun 30, 2007
    Posts:
    12,828
    Likes Received:
    1,707
    Location:
    West of Transylvania
    Listen near the air springs when the engine is started and if you hear a hissing noise it means it's a leak... changing a bag is easy... you are not mechanic but do you have tools and are you handy enough to carry out some jobs with guidance ?

  3. Cromarty

    Cromarty New Member

    Joined:
    Jan 6, 2020
    Posts:
    7
    Likes Received:
    0
    Location:
    72240 Saint Symphorien France
    Thank you, I have tried this and no hissing

  4. sierrafery

    sierrafery Well-Known Member

    Joined:
    Jun 30, 2007
    Posts:
    12,828
    Likes Received:
    1,707
    Location:
    West of Transylvania
    What about the sensors? can't you see one snapped or detached ?, see image below. ... also answer what kind of works are you up to do cos if you are not able to improvise a wiring or handle some tools we are speaking in vain

    [​IMG]

  5. Cromarty

    Cromarty New Member

    Joined:
    Jan 6, 2020
    Posts:
    7
    Likes Received:
    0
    Location:
    72240 Saint Symphorien France
    My uncle is willing to give me a hand and has some jacks etc, if he knows what to do - expert advice from you guys ? I will go check the sensors but i looked before and couldnt see anything untoward

  6. sierrafery

    sierrafery Well-Known Member

    Joined:
    Jun 30, 2007
    Posts:
    12,828
    Likes Received:
    1,707
    Location:
    West of Transylvania
    If no visible issue with the sensors and no evidence of leak it can be a management or wiring issue too, an easy thing which worth a try is to disconnect the battery then unplug the connectors of the sensors and see if the wirings are ok into the pins, give some contact spray and connect them back... if no change afer that you can make an improvisation to inflate the bags: unplug everything in the compressor housing, improvise a wiring as to feed the compressor and the two air supply valves at the same time... if u feed these and it starts to rise let it untill the aprox normal level and cut the feed. Leave everything unplugged and wait... if there is no leak along the system it can stay levelled for days dont worry... at least you'll know it's something else... see this: SLS disaster! Please help

    if that seems hard her's another option https://www.ebay.co.uk/itm/DISCOVER...L-INFLATION-BYPASS-4MM-OD-VALVES/282534767304

    and the ultimate bodge as to be able to go unill a garage is to jack it up and stick in wood blocks under the bump stops as in the pic, good luck

    SLS wood fix.jpg

  7. Nig43

    Nig43 Active Member

    Joined:
    Mar 31, 2018
    Posts:
    110
    Likes Received:
    16
    Location:
    TAMWORTH, STAFFS
    Exhaust solenoid stuck open on the air compressor?

  8. Cromarty

    Cromarty New Member

    Joined:
    Jan 6, 2020
    Posts:
    7
    Likes Received:
    0
    Location:
    72240 Saint Symphorien France
    Thanks all, where am i looking to find the compressor ?

  9. Landmark2

    Landmark2 Active Member

    Joined:
    Aug 1, 2013
    Posts:
    514
    Likes Received:
    67
    Location:
    Shropshire
    Near side chassis rail -enclosed in plastic box
    Griff

  10. Cromarty

    Cromarty New Member

    Joined:
    Jan 6, 2020
    Posts:
    7
    Likes Received:
    0
    Location:
    72240 Saint Symphorien France
    many thanks
