****e!! so would i be better off changing the entire Axle?
Diff leaking oil, Help please.
- Thread starter P38_Ireland
- Start date
This site contains affiliate links for which LandyZone may be compensated if you make a purchase.
- Posts
- 83,310
- Location
- Embasinga stocæ
Pm Trewy, coz he had one done - it's not just changing the diff, it's changing the axle casing.
Do yu know a really good welder, if so ask him.
until then remove half shafts, remove diff, wash the casing in petrol and then drive in difflock - or stuff the hole with metal mastic.
Do yu know a really good welder, if so ask him.
until then remove half shafts, remove diff, wash the casing in petrol and then drive in difflock - or stuff the hole with metal mastic.
jamesmartin
Well-Known Member
- Posts
- 91,879
- Location
- louth lincs
they are not to bad to weld in fact fairly straight forward case isnt cast its pressed steel ,the hardest bit is making sure you dont end up with pin holes in weld,it would be easier to swap all your parts if in good nick to fresh case,remembering 200tdl def and before cases have thinner radius arms than 300 on ,300 on uses same case as disco 200 or 300 but some come without roll bar brackets on earlier 200 disco
Trewey
Cockernee, Pasty munchin bastid.
- Posts
- 20,091
- Location
- Kernow - Near England
cut off old one, clean area scrupulously and weld noo one on.
prob is yu are welding a thin metal plate to a heavy cast lump - not an easy job - even for the pros.
The replacement pans are a nice tight fit in the casing. Mine was just tack welded in place, then a seam of JB Weld all around the perimeter. It's worked fine (been done 3 years now). After all, it's only to hold the oil in and keep the dirt out - not under any load or pressure.
P38_Ireland
Well-Known Member
- Posts
- 1,392
- Location
- Co Wexford, Ireland
i think im going to change the axle and be done with it
P38_Ireland
Well-Known Member
- Posts
- 1,392
- Location
- Co Wexford, Ireland
well as i decided to change the axle i got on with it today. ran in to 1 or 2 little annoying buts but all striped out now. im going to change the seals on the swivel joints (there very rusted and might as well do it on the bench now for easyness) but so far so good. new axle arriving tomorrow but i think the seals wont hbe here till friday so will have to wait till then, here are some pics of my progress
new axle
new axle
jamesmartin
Well-Known Member
- Posts
- 91,879
- Location
- louth lincs
your taking a risk on those blocks
CwazyWabbit
Member
- Posts
- 62
- Location
- Caterham
That's a fairly meaty looking guard
bustersbus
Well-Known Member
- Posts
- 13,755
- Location
- Near Dumfries, Scotland
Guid yin
P38_Ireland
Well-Known Member
- Posts
- 1,392
- Location
- Co Wexford, Ireland
whats not a risk with a landrover??? lol
Guid yin
thanks dude would have been lost without your walk through.
P38_Ireland
Well-Known Member
- Posts
- 1,392
- Location
- Co Wexford, Ireland
Just an update, got the new axle today cleaned it down and painted it (not to everyones taste im sure!!) waiting on gaskets and seals to arrive tomorrow or friday and then refit the axle
- Posts
- 83,310
- Location
- Embasinga stocæ
not sure that protection is my cup of tea - yu can still get big rocks punch thru the diff casing. But it wont trap mud, thats for sure .
.
P38_Ireland
Well-Known Member
- Posts
- 1,392
- Location
- Co Wexford, Ireland
success lads, done and dusted, referbed the ball joints new axle, new track rod and track rod ends took it out for a test drive this evening and all seems well. thanks for all the help and tips
