Defender bonnet pops

Discussion in 'Defender 90 / 110 / 130' started by Taffy1, Jan 11, 2017.

< Previous Thread | Next Thread >
  1. Taffy1

    Taffy1 New Member

    Joined:
    Jan 11, 2017
    Posts:
    6
    Likes Received:
    0
    Location:
    Bath
    I've got a 2010 Defender 90 and the bonnet keeps popping open onto the safety catch. I've adjusted the length of the pin, the position of the locking mechanism plus the two rubber stops and I still can get it stay close. It clicks down but will pop up due to road vibration on the move or if you manually try and shake or pull the bonnet whilst stationary . Any suggestions ? Do I need to change the pin or locking mechanism . Thanks

  2. Oldseadog

    Oldseadog Well-Known Member

    Joined:
    May 27, 2011
    Posts:
    9,270
    Likes Received:
    1,051
    Location:
    Tynemouth
    Have you got the spring in the right place?
    There is a hole in the slide at the opposite end from the cable clamp, and if the spring is in there the bonnet will keep popping (how do I know this?)
    I have found that if the spring is attached to the little bracket by the cable end, then everything is OK.
    I used a spring from an old mini seat, which I made fit. ;)
    Got to admit that it is as fiddly as hell to get it right as you are working blind!
    Hope this helps.

  3. mikescuba

    mikescuba Well-Known Member

    Joined:
    Dec 26, 2009
    Posts:
    2,726
    Likes Received:
    741
    Location:
    France, Loire, Rhone Alpes
    Get a bonnet catch like mine, problem solved

  4. Al2O3

    Al2O3 Well-Known Member Full Member

    Joined:
    Apr 21, 2014
    Posts:
    9,863
    Likes Received:
    3,767
    Location:
    North of the Wall
    This is a picture of what Oldseadog has described. From a 1996 Defender 90, anyway. :rolleyes:
    [​IMG]
    You can see the spring Oldseadog described. It's under a lot of tension, or should be! I can see the end of that spring when I open the bonnet.
    Don't know if your 2010 model will be the same as this, so hope this helps.

    Oldseadog likes this.
  5. Oldseadog

    Oldseadog Well-Known Member

    Joined:
    May 27, 2011
    Posts:
    9,270
    Likes Received:
    1,051
    Location:
    Tynemouth
    Thanks for that A1203.
    It was a bit cool for me to go out and remove the grille off and take some piccies.

  6. tottot

    tottot Well-Known Member

    Joined:
    Nov 7, 2010
    Posts:
    5,189
    Likes Received:
    1,439
    Location:
    west wales coast
    A release cable that has gone stiff and is not fully returning can give that problem,but yours is a bit young for that.

  7. Dippypud

    Dippypud Never Knowingly Understood Full Member

    Joined:
    May 2, 2011
    Posts:
    57,101
    Likes Received:
    34,214
    Location:
    The Wooly Witch
    If the grease is a bit frozen ?

  8. Tim4x4

    Tim4x4 Well-Known Member

    Joined:
    Dec 15, 2013
    Posts:
    1,427
    Likes Received:
    116
    Location:
    In the shed
    Also clean out the pin guide that the locking pin travels into, this can after time fill with mud and crud stopping the pin fully engaging with the locking mechanism.
    It is the centre guid upload_2017-1-13_17-29-57.png e in the picture which has a drain hole in it.

  9. ogb

    ogb Active Member

    Joined:
    Jun 2, 2015
    Posts:
    288
    Likes Received:
    81
    Location:
    Moray, NE Scotland
    Is that because you carry a spare wheel on the bonnet, Mike? I do the same and need to wedge the safety catch open if I need to lift the lid because of the extra weight. I got round this by fitting "rally clips" to the bonnet. Maybe this is an easy fix to the OP's problem?

  10. ogb

    ogb Active Member

    Joined:
    Jun 2, 2015
    Posts:
    288
    Likes Received:
    81
    Location:
    Moray, NE Scotland
    Ah...just re-read the OP's question...a 2010 model can't carry a spare on the bonnet, can it?

  11. Al2O3

    Al2O3 Well-Known Member Full Member

    Joined:
    Apr 21, 2014
    Posts:
    9,863
    Likes Received:
    3,767
    Location:
    North of the Wall
    Too cool for me too, mate. Hunted that picture out from the rebuild pictures. ;)
