Can anyone ID this part please?

bankz5152 said:

Part 13 on the diagram -

Been looking for ages and not found anything, ordered what I though was the correct part but doesn't much the rest of the wheels. It's the same size as the lock washers but considerably thicker, pushes up against the outer wheel bearings.

Thanks.

Click to expand...

Marmaduke said:

Slightly different image but is it item 12 in the diagram?

http://www.johncraddockltd.co.uk/search/results.html?s=217352&sb=Search

Click to expand...

jamesmartin said:

it used to be,that then became the D type ftc3185 then the ftc5241

Click to expand...

Marmaduke said:

Craddocks still list it for older axles whereas your part seems for newer ones including Discovery ones

Click to expand...

bankz5152 said:

2002 TD5 90. I ordered what I thought was the right one, it does fit and it is the correct thickness but the outer width is much thinner if you see what I mean? Don't really want to use it as it looks like the ftc5241 part will keep the grease in better, if that even matters?

Thanks James, according to the various pics I've found that looks like the correct part!

Click to expand...
