an bollix tur drippy ...he aint gonna be able to drive down there before xmas...it'll tek him two weeks to get up the hill at the end of his road
200Tdi upgrade begins
- Thread starter Patman1200
- Start date
This site contains affiliate links for which LandyZone may be compensated if you make a purchase.
oil dripper
Well-Known Member
- Posts
- 5,659
- Location
- Here i think
Sirus
Your all Banned except me
- Posts
- 22,196
- Location
- The Country of Black
ere when yur coming down tur fix me winch on......bring your shiny drill bits too
oil dripper
Well-Known Member
- Posts
- 5,659
- Location
- Here i think
Sirus
Your all Banned except me
- Posts
- 22,196
- Location
- The Country of Black
Iss a fookin heavy bastid
oil dripper
Well-Known Member
- Posts
- 5,659
- Location
- Here i think
ya got them quality genuine springs to tek the weight intya
Sirus
Your all Banned except me
- Posts
- 22,196
- Location
- The Country of Black
Its the lifting it up and positioning it whats gonna be the killer...
Sirus
Your all Banned except me
- Posts
- 22,196
- Location
- The Country of Black
am free , monday tuesday wednesday , thursday, saturday
oil dripper
Well-Known Member
- Posts
- 5,659
- Location
- Here i think
feck me ya gorra enjun lift ya aquired from some poor bloke intya
oil dripper
Well-Known Member
- Posts
- 5,659
- Location
- Here i think
so wot ya doin tomorra? am good till about 2 cus i gorra tek the littlun to a party at 3.00
jai_landrover
Well-Known Member
- Posts
- 13,392
- Location
- Luton
The vulcan in flight! Amazing!
oil dripper
Well-Known Member
- Posts
- 5,659
- Location
- Here i think
oil dripper
Well-Known Member
- Posts
- 5,659
- Location
- Here i think
TheVengefulElephant
Well-Known Member
- Posts
- 6,527
met me first missus stood underneaf the vulcan that that museum were restoring.
that is very sad that is ..... i used to go there quite often ta collect scrap aircraft parts from goldstar engineering .... thats sad....
yella
New Member
- Posts
- 15,991
At this rate in about 3 months time
To add to the delay this is what flew over my house this afternoon
Beauty in flight! My hat goes off to the team who got it back into the air!
kinell they seem to have shortened the nose since it stopped doin the supersonic transatlantic
Patman1200
Active Member
- Posts
- 908
- Location
- RAE Sleepy Valley
Last night I did some measuring and checking of parts for the final assembly of the 200.
There are 2 mounting lugs on either side of the rad/intercooler frame that have to be cut off. When I mounted the rad/intercooler into the supports on the front I found that indeed the rad/intercooler are about 3cm too high for the TD radiator holder brackets to fit over the 200Tdi rad.
So the mounts will have to be cut down and welded.
With the rad in place I took some measurements and checked that I had all the pipework needed to complete this.
Water pipes:- About 40-42mm internal diameter- The Tdi ones aren't long enough but the TD ones are, so don't need to buy any more.
Internal heater hoses:- The TD ones aren't long enough but the ones out of the Disco are.
Oil cooler pipes:- About 30cm too short, so I have taken them to Pirtek to have them extended (about £60) by 30cm. Pirtek UK : Europe's Number One provider of fluid transfer solutions & on-site repairs for hydraulic hoses, pipe fittings & couplings : Hose Reels, Hydraulic Oil, Hydraulic Fittings, Hose Fittings, Stainless Steel Fitting, Stainless Steel Pipes, Stai
Fuel Pipes:- Using the Tdi filter then pipes are too short to mount the filter onto the bulkhead where the TD one went. Got some 8mm ID fuel hose from a motor factor for £5. There are 2 pipes to the filter that need extending so I will just cut the pipes and slip on the new hose so that the filter can be mounted in the same place as the TD one. Then there are the fuel tank and spill return pipes to connect up. As these aren't hight pressure then I will just join the pipes up using the same fuel hose.
Turbo-intercooler pipework:- After a lot of measuring and playing with all the pipes I have I know I haven't got anything that will work, especially the turbo output pipe that is very close to the innter wing. I am going to splash out on some bling
Air intake is the last thing to look at. I have the flexy hose from both the TD and Tdi so I think I shold be ok for that. It's just deciding where to mount the air filter.
Here are some photos of the lower turbo output that needs a very tight curve hose.
Input to the intercooler
Intercooler output to the engine
Lower water hose that isn't quite long enough.
Internal water heater hoses
How soon do you think the rad will last with fins like this????
There are 2 mounting lugs on either side of the rad/intercooler frame that have to be cut off. When I mounted the rad/intercooler into the supports on the front I found that indeed the rad/intercooler are about 3cm too high for the TD radiator holder brackets to fit over the 200Tdi rad.
So the mounts will have to be cut down and welded.
With the rad in place I took some measurements and checked that I had all the pipework needed to complete this.
Water pipes:- About 40-42mm internal diameter- The Tdi ones aren't long enough but the TD ones are, so don't need to buy any more.
Internal heater hoses:- The TD ones aren't long enough but the ones out of the Disco are.
Oil cooler pipes:- About 30cm too short, so I have taken them to Pirtek to have them extended (about £60) by 30cm. Pirtek UK : Europe's Number One provider of fluid transfer solutions & on-site repairs for hydraulic hoses, pipe fittings & couplings : Hose Reels, Hydraulic Oil, Hydraulic Fittings, Hose Fittings, Stainless Steel Fitting, Stainless Steel Pipes, Stai
Fuel Pipes:- Using the Tdi filter then pipes are too short to mount the filter onto the bulkhead where the TD one went. Got some 8mm ID fuel hose from a motor factor for £5. There are 2 pipes to the filter that need extending so I will just cut the pipes and slip on the new hose so that the filter can be mounted in the same place as the TD one. Then there are the fuel tank and spill return pipes to connect up. As these aren't hight pressure then I will just join the pipes up using the same fuel hose.
Turbo-intercooler pipework:- After a lot of measuring and playing with all the pipes I have I know I haven't got anything that will work, especially the turbo output pipe that is very close to the innter wing. I am going to splash out on some bling
Air intake is the last thing to look at. I have the flexy hose from both the TD and Tdi so I think I shold be ok for that. It's just deciding where to mount the air filter.
Here are some photos of the lower turbo output that needs a very tight curve hose.
Input to the intercooler
Intercooler output to the engine
Lower water hose that isn't quite long enough.
Internal water heater hoses
How soon do you think the rad will last with fins like this????
Patman1200
Active Member
- Posts
- 908
- Location
- RAE Sleepy Valley
It looks liek the intercooler pipes might be in the way...... but until I fit it all I'm not sure. I'd like to keep it there somehow.
Yup new rad it is, but not yet. T think it is something worth buying new
Yup new rad it is, but not yet. T think it is something worth buying new
