2002 Td6 Suspension issues

Discussion in 'Range Rover' started by Fran Mcauley, Jan 4, 2019.

< Previous Thread | Next Thread >
  1. Fran Mcauley

    Fran Mcauley Member

    Joined:
    Nov 27, 2017
    Posts:
    19
    Likes Received:
    1
    Location:
    Northwest England
    I have a 2002 TD6 Range Rover..
    The fault I’m after some pointers about is as follows...
    When I start it up the suspension works fine, orange lights at the switch etc are on and suspension can be adjusted to any height... But after a few minutes it switches off and to reactivate it I have to turn the ignition off and on then it works fine again for a few minutes!!??... any ideas guys.. also anyoneknow what this is on the screen display-when touched it turns green then goes redagain..


    Attached Files:

  2. Saint.V8

    Saint.V8 Dyed-in-the-wool 100% RR Junkie

    Joined:
    Apr 27, 2008
    Posts:
    16,325
    Likes Received:
    2,103
    Location:
    Wiltshire - Nadder valley - its rather pretty
    Are you sure it is a 2002 - touchscreen was 2006 onwards.....

  3. Fran Mcauley

    Fran Mcauley Member

    Joined:
    Nov 27, 2017
    Posts:
    19
    Likes Received:
    1
    Location:
    Northwest England
    Yes definitely a 2002, it is the facelift model though.. touchscreen but no sat nav

  4. myfirstl322

    myfirstl322 Well-Known Member

    Joined:
    Dec 29, 2012
    Posts:
    25,016
    Likes Received:
    10,433
    Location:
    Geroutavit.....
  5. Saint.V8

    Saint.V8 Dyed-in-the-wool 100% RR Junkie

    Joined:
    Apr 27, 2008
    Posts:
    16,325
    Likes Received:
    2,103
    Location:
    Wiltshire - Nadder valley - its rather pretty
    There was no touchscreen in the 2002-2005 L322's it came in on the 55 plate (2006MY) when they fitted the fibre optic media system called MOST (Media Orientated System Transport).

    I think the icon is for the suspension inhibit switch......

    I think you would need to plug it into diagnostics to find out if the EAS ECU is showing any fault codes.....but I am confused as you say it is a 2002, but it has the 2006 touchscreen, and there were two major facelift periods - 2006 and 20010/11

  6. Fran Mcauley

    Fran Mcauley Member

    Joined:
    Nov 27, 2017
    Posts:
    19
    Likes Received:
    1
    Location:
    Northwest England
    Well, the issue of it having a touchscreen doesn’t really bother me and I was after some pointers to maybe stop having to do diagnostic stuff.. I’ve had a diagnostic plugged in for something else and it didn’t show any suspension issues...as for the icon- I would be interested to know what it actually is supposed to do- should it turn green and stay green also...

  7. gold rover

    gold rover Well-Known Member

    Joined:
    Nov 22, 2010
    Posts:
    7,598
    Likes Received:
    4,772
    Location:
    Scotland,
  8. Mark Piercy

    Mark Piercy Well-Known Member

    Joined:
    Jul 11, 2016
    Posts:
    6,754
    Likes Received:
    2,914
    Location:
    sud ouest France
  9. Mark Piercy

    Mark Piercy Well-Known Member

    Joined:
    Jul 11, 2016
    Posts:
    6,754
    Likes Received:
    2,914
    Location:
    sud ouest France
    Which diagnostic tool was used on your bus @Fran Mcauley .
    Some don't give all the info and these peeps can tell you which is best for your bus;)

  10. Saint.V8

    Saint.V8 Dyed-in-the-wool 100% RR Junkie

    Joined:
    Apr 27, 2008
    Posts:
    16,325
    Likes Received:
    2,103
    Location:
    Wiltshire - Nadder valley - its rather pretty
    I am not dissing the touchscreen - the point I am making, which you fail to grasp, is that the 2002-2005 did not have the touchscreen fitted as it is NOT compatible with the wired (copper) data buses and was ONLY fitted to the 2006MY and onwards vehicles that were fitted with the Ford MOST fibre Optic system.

    My point being, if it is indeed fitted to a 2002 vehicle you will find that it may not work correctly or in the way it was originally designed.

    The EAS system on the 2002-2005 model year was controlled via a manual knob on the lower part of the centre console, the later models were controlled using the touch screen.

    Unless there are some fecking super modding geniuses out there who have managed to get the old aged CANbus data system to talk with the MOST Fibre Optic system then the height functions and EAS controls on the touchscreen may not even have any function at all....

    Do you have the terrain response Mode dial by the Drive selector?

    Henry_b likes this.
  11. Henry_b

    Henry_b Pist'N'Broke

    Joined:
    Jan 29, 2018
    Posts:
    12,198
    Likes Received:
    11,051
    Location:
    Hereford****e
    'Ave a look in the instruction manual it might give you some pointers as to what the warning means..

    Most of my owners manual is a chapter regarding warning lights...

    Check the battery condition and output voltage of the alternator, these get real skittish when the battery is poor or the alt is tired..

  12. Mark Piercy

    Mark Piercy Well-Known Member

    Joined:
    Jul 11, 2016
    Posts:
    6,754
    Likes Received:
    2,914
    Location:
    sud ouest France
    Ooh, I feel there may be a nail to be knocked on the head here??o_O

  13. myfirstl322

    myfirstl322 Well-Known Member

    Joined:
    Dec 29, 2012
    Posts:
    25,016
    Likes Received:
    10,433
    Location:
    Geroutavit.....
    ...and I'm all out of pop corn.:(

    Mark Piercy likes this.
  14. Henry_b

    Henry_b Pist'N'Broke

    Joined:
    Jan 29, 2018
    Posts:
    12,198
    Likes Received:
    11,051
    Location:
    Hereford****e
    [​IMG]

  15. Mark Piercy

    Mark Piercy Well-Known Member

    Joined:
    Jul 11, 2016
    Posts:
    6,754
    Likes Received:
    2,914
    Location:
    sud ouest France
    Arrr, how weird is that, I was going to say Henry'll have some!!!:D

  16. Fran Mcauley

    Fran Mcauley Member

    Joined:
    Nov 27, 2017
    Posts:
    19
    Likes Received:
    1
    Location:
    Northwest England
    The touchscreen works fine with the functions on it- radio,cd player,4x4 section and phone..no suspension options on the touchscreen except for showing the height and steering angle- the suspension is controlled by a knob with orange lights and there is a hill decent and terrain switch near the gear lever...

  17. myfirstl322

    myfirstl322 Well-Known Member

    Joined:
    Dec 29, 2012
    Posts:
    25,016
    Likes Received:
    10,433
    Location:
    Geroutavit.....
  18. Fran Mcauley

    Fran Mcauley Member

    Joined:
    Nov 27, 2017
    Posts:
    19
    Likes Received:
    1
    Location:
    Northwest England
    I will take a picture tomorrow and add it.

  19. Fran Mcauley

    Fran Mcauley Member

    Joined:
    Nov 27, 2017
    Posts:
    19
    Likes Received:
    1
    Location:
    Northwest England
    An expensive snap on diagnostic was used

  20. Saint.V8

    Saint.V8 Dyed-in-the-wool 100% RR Junkie

    Joined:
    Apr 27, 2008
    Posts:
    16,325
    Likes Received:
    2,103
    Location:
    Wiltshire - Nadder valley - its rather pretty
    If you have the terrain response system fitted - it is NOT a 2002....

    Henry_b likes this.
