After removing my bonkers immobiliser, I'm reconnecting the wires and need a wee swatch of advice.
Following the wires running down from the ignition switch I have:
Brown----battery I assume
White n Red----starter?
Orange and white---ignition, fusible link?
Fat white--- assume load relay and stuff
If I match up the connectors where they were cut, it would seem to be:
Brown---> Orange and Brown
White n red--->Black and white
Orange and white just bypasses the plug on mine
FAt white goes to the other fat white
Is this correct?
Different diagrams show different things. I have a 1992.
