Series 3 Chassis Welding.

layfin · Sep 6, 2019

Hi All.
I have just purchased a new Wolf 130 Mig Welder. Could anyone recommend the setting I should use to weld on sections of 2mm Steel. I have tried various settings already, however, none seem to be very good.
Also, one uTube video suggesting welding without the Shroud covering the Tip. Is this a good idea ?.
Best regards.
Chris.

Flossie · Sep 6, 2019

layfin said:
Hi All.
I have just purchased a new Wolf 130 Mig Welder. Could anyone recommend the setting I should use to weld on sections of 2mm Steel. I have tried various settings already, however, none seem to be very good.
Also, one uTube video suggesting welding without the Shroud covering the Tip. Is this a good idea ?.
Best regards.
Chris.

No shroud? That's cobblers.
Is it gasless?

layfin · Sep 6, 2019

yes. flux core.

rob1miles · Sep 6, 2019

Just spent the day welding up my trailer floor, 22 patches (I think its on its last legs...). I'm using it as my training before I weld the bulkhead, there's no substitute for practice!. The one way is to get some scrap and weld with one hand on the speed knob and make small adjustments until it sounds right and keeps steady arc. Start slow and come up. Have you go the polarity right for gasless? Do you have power and speed settings? For 2 mm try the meduim or high power and start on a slow speed. Is it an inverter type?

tottot · Sep 6, 2019

Get on to MIG welding forum, lots of good info.

Kev12 · Sep 6, 2019

If you can run it with standard wire and gas it will give better results

Colthebrummie · Sep 7, 2019

Gasless will always be inferior I'm afraid, unless you are a Jedi master of welding.

Col

Bobsticle · Sep 7, 2019

Start with everything on eleven.

By the time you’ve built up all the holes you’ve blown in it you’ll be quite good at it.

layfin · Sep 7, 2019

rob1miles said:
Just spent the day welding up my trailer floor, 22 patches (I think its on its last legs...). I'm using it as my training before I weld the bulkhead, there's no substitute for practice!. The one way is to get some scrap and weld with one hand on the speed knob and make small adjustments until it sounds right and keeps steady arc. Start slow and come up. Have you go the polarity right for gasless? Do you have power and speed settings? For 2 mm try the meduim or high power and start on a slow speed. Is it an inverter type?

layfin · Sep 7, 2019

There is a Speed Knob and 4 Power Settings, Min, Max, 1 and 2.

Colthebrummie · Sep 7, 2019

I'm assuming by the name of your welder, it's a 130 amp. You might find it blows/trips your house fuse on full power. The thicker the metal being welded, the more power you need

Col

steve2286w · Sep 7, 2019

I’ve got the Clarke 150, you can see the manual online, it’s prob similar
https://www.clarkeservice.co.uk/manuals2/mig130_150te.pdf

As a starter have a look at some you tube videos

Kev12 · Sep 7, 2019

Settings will be either 1max or 2 min for 2mm at a guess and wire feed prob a bit over halfway. Make sure you clean well, makes a big difference

layfin · Sep 7, 2019

Its a Wolfweld 25 -130.

Zed. · Sep 7, 2019

Colthebrummie said:
Gasless will always be inferior I'm afraid, unless you are a Jedi master of welding.

Col

yes & no....

fluxcore has it's uses in industry, as a hobby-weld it's not great BUT then most 'hobby' welders are not great (both the sets & 'weldists'

)

as to the OP.

practace & practace before attacking the chassis, remember that you could be towing & your repair is what holds the trailer on

( possibly a 'worst-case scenario but.....)

clean metal (both sides if possible), if outdoors a 'tent' is usefull to stop wind causing swearing, try to get comfy or at least have good access to the area that's being repaired...

ALSO

Fire-extingushers

Rich.

tottot · Sep 7, 2019

A good quality auto mask so you can see what is happening. Also helps to have good light on the task.

rob1miles · Sep 7, 2019

Agreed re Min 2 or Max 1, try Min 2 first on some scrap and break a few or saw them up to make sure you are getting decent welds.. Practice and not only get it very clean but also get into position and make sure you can get the angle you need all along the weld.
I've not had much success in the past with gasless but doing this trailer outside (and its been windy) the latest gasless wire with the inverter mig had been really good. I don't think i could have done it with gas without building a habitat. Its been at least 12 ft of weldng. This has all been 1.5 to 2mm and not structural so I'd want to see the penetration on bigger welds before using gasless on the chassis.

layfin · Sep 9, 2019

Thanks, this is the basic information I am looking for. I will give it a try during the week and keep you posted.
