200Tdi upgrade begins

Aye not many hills around there.
You still ok for Friday and the big swap?

Yup doing the final disconnection tonight (with photos for those who like pictures ) and a final feel up of the bellhousing (fnar fnar!) to make sure I haven't missed any bolts and studs.

cant be bothered to read through 5 pages so apologies if this has already been said.

but if i were you i would replace the rear crank seal on the tdi lump as well.

I did a 200tdi conversion into my 90 in february, and then about a month ago it started ****ing oil out between the flywheel housin and bellhousin on the gearbox. so i had to drop the gearbox to replace the rear crank seal! bit of a pain really, although i took the opportunity to fit the disco transfer box as well which i had been planning on doing for a while.

Nope hadn't been mentioned in the last 5 pages, but it is now on the list of things to do, ta!

Last nights attack on the 110 was
Fuel filter removed. I snipped the return pipe.


Undid teh main fuel pipe to the lift pump.


Removed the brake vacuum hose


Removed the heater pipes.


and undid the last 2 bellhousing bolts


So apart from the starter motor wiring it's ready to come out

get yerself a nice slim but strong pry bar ready for splitting the GB and engine cos they is usually stuck together with magic invisible glue

and have someone stood on the rear cross bar of yer hoist when it takes the weight

I have a feeling this one will come apart quite easily as all the bolts I have removed from the engine bay so far have been clean. It looks like this engine has been replaced in the recent past.
When they did they didn't do a very tidy job of the wiring and didn't bother connecting the water temperature sender as it was the other end of the engine.

Sean said:

have someone stood on the rear cross bar of yer hoist when it takes the weight

Click to expand...

That will be my job then.
Pass another pie thanks.

u putting a leccy fan in Pat ?

another job to add to yer list while everything is out is to undo the heater and clear out all of the crap that tends to gather around the ickle rad - and soak it in some CH rad flush - makes a lot of difference to how well the cabin heating works

Cabin heater worked really well, as did the one in my 109. But I will be flushing out the read, intercooler and cabin heater anyway. Good thinking!The list of jobs has been added to my spreadsheet of tasks.

Not decided on a leccy fan yet. I'll see how hot the engine does or doesn't get, with and without the viscous fan.

Did you replace the turbo pipework?

Patman1200 said:

Not decided on a leccy fan yet. I'll see how hot the engine does or doesn't get, with and without the viscous fan.

Did you replace the turbo pipework?

Click to expand...

it'll be fine most of the time without a fan but what happens if you need to drag a few ton up the M6 or do anything thats going to get the engine working hard ? - jump out and fit one ?

i tend only to change the intercooler to turbo pipe as i can't see how else to do the plumbing without buying a new length

i've also started putting a tee in the turbo actuator pipe and running a 2-3mm flexi pipe up to the dash as it's another arse of a job to fit when you get round to fitting a boost guage (and you will eventually) - dont forget to blank it off untill you do fit a guage

What do you use for the turbo/intercooler and intercooler/intake manifold pipe to extend them?

I don't do any heavy work with the 110, but just in case I'll carry the viscous fan in the back.

Patman1200 said:

What do you use for the turbo/intercooler and intercooler/intake manifold pipe to extend them?

I don't do any heavy work with the 110, but just in case I'll carry the viscous fan in the back.

Click to expand...

i tend not to extend just replace the pipework - you'll also find that the viscous fan will foul the PS relay unless you use a disco bellhousing and swop all of the GB linkages around so the engine sits forward

these are very good fer bits of hose and odds and sods

eBay My World - autoperformanceonline

Ahhhh all these things to play with when I get the new 200 in

youve broken it now

Swearing man & machine! Think the Landy was winning! MBG x

is it cold there ?

Nope, but very oily, as per all Landies.

MadBikerGoth said:

Swearing man & machine! Think the Landy was winning! MBG x

View attachment 6406

View attachment 6407

Click to expand...

pfftttt .... he's got gluvs on ...... worra puff....
