Valve/Cam timing Petrol 2.25- am I over thinking this??

Discussion in 'Series Land Rovers' started by MFC, Apr 10, 2021.

< Previous Thread | Next Thread >
  1. MFC

    MFC Active Member

    Joined:
    Jan 20, 2010
    Posts:
    153
    Likes Received:
    21
    Here is the old cam which is I hope the same as the new, Number one lobe lined up with the keyway (this I have checked with new one) Number 4 is 90 deg to number one. As the keyway is aligned with the P on the sprocket number one lobe is where the P is (or should be). Still confused here


    Attached Files:

    • Cam1.jpg
      File size:
      105.2 KB
      Views:
      47
  2. MFC

    MFC Active Member

    Joined:
    Jan 20, 2010
    Posts:
    153
    Likes Received:
    21
    Ok I have given some thought on this. It seems that on the factory marks 'P' and with the crank keyway pointing up the timing is 180 degrees out ie exhaust just closed and inlet valve just about to open on induction stroke . So if I set it up per the book the timing will be out by the 180 which I assume will cause the problem of the Distributor needing to be 180 out (have seen this on a few engines) but apart from that nothing bad will happen (as the crank does not know what stroke the pistons are on)
    So I plan to install the cam 180 out (as per book) so that the TDC will be on the compression stroke.

    I have heard lots of people with Distributor problems ie wrong orientation and wonder if this could be part of the problem.
    I can't believe this is a problem with all timing of a series cam but you might wonder.
    I have just put the chain on to check and yes timing is 180 out according to marks. So either dodgy sprocket, or?????
    Please feel free to comment as I can't believe this is a common issue.
