Tow bar question

This site contains affiliate links for which LandyZone may be compensated if you make a purchase.
neo2

neo2

Active Member
Posts
397
Location
Crook/ Durham..
Can or is there a option to bolt a towbar to this bar in the pic below or does this come off etc as it appears to welded to chassis ??


You have to mount another cross bar right behind the bumper, the tow bar is attached to this bar, and then everything is bolted to the bar you see in your picture.

Got a tow bar with detachable ball section so soon as i get my EBCM back and get her running i will try it on lol... do you need percific electrics for these or can you just solder into the rear light looms etc ???

neo2 said:
Got a tow bar with detachable ball section so soon as i get my EBCM back and get her running i will try it on lol... do you need percific electrics for these or can you just solder into the rear light looms etc ???
Click to expand...

Do NOT solder or connect into the rear light looms, the BECM will not like it. The trailer wiring sits behind the trim in the boot, the main one on the drivers side, auxillary on the passenger side. The BECM will know when the trailer lights are connected.:)

DATATEK thanks for the heads up i thought i would be the case as my RRS had the plug already there too, just wasnt sure this being as old as it it etc

Sandyt Ha ha everything i do will be double checked from now not paying for another Becm repair lol....

Should be - all 12N sockets are the same configuration of pins...

There should be a loom in the boot area behind one of the side panels to hook it up to - it might not be plug and play as such, so you may have to get funky with either splicing into this loom or making connections some how....

Pin out as attached.....


Attachments

  • 12N_Socket_wiring.gif
    6.5 KB · Views: 439
Further reading in RAVE indicates that there are indeed spare plugs in the required lighting looms (Fog, Stops, Indicators, Tails, Reverse) that the Trailer Socket will plug into (each lighting circuit will have seperate plugs - so don't expect one plug to plug it into - there will be 4/5 of them)

Saint.V8 said:
Further reading in RAVE indicates that there are indeed spare plugs in the required lighting looms (Fog, Stops, Indicators, Tails, Reverse) that the Trailer Socket will plug into (each lighting circuit will have seperate plugs - so don't expect one plug to plug it into - there will be 4/5 of them)
Click to expand...


There is a single plug each side, drivers side for what the UK call 12N, passenger side 12S:)

Datatek said:
There is a single plug each side, drivers side for what the UK call 12N, passenger side 12S:)
Click to expand...
I stand Corrected then....sure in RAVE looking at the Trailer Socket Connection Schematics, it shows different plugs for each lighting circuit - and also reference in the Connector views too....Something like C330 up to C336 or something!!

But I could be and usually am wrong when it comes to sparks!!

Saint.V8 said:
I stand Corrected then....sure in RAVE looking at the Trailer Socket Connection Schematics, it shows different plugs for each lighting circuit - and also reference in the Connector views too....Something like C330 up to C336 or something!!

But I could be and usually am wrong when it comes to sparks!!
Click to expand...

Well it is certainly a single multi pin connector each side on mine as I needed to mod the trailer wiring to suit the continental 13 pin trailer socket:)
