Disco 2 Oil Leak

Discussion in 'Land Rover Discovery' started by Intestinalworm, Jan 4, 2020.

< Previous Thread | Next Thread >
  1. sierrafery

    sierrafery Well-Known Member

    Joined:
    Jun 30, 2007
    Posts:
    14,889
    Likes Received:
    2,558
    Location:
    West of Transylvania
    You was under the right impression, it's there below the ''half-moon" section, ERR5369

    Td5 rear camshaft seal.jpg

    Intestinalworm and tilly2 like this.
  2. iansoady

    iansoady Active Member

    Joined:
    Oct 11, 2006
    Posts:
    629
    Likes Received:
    57
    And I believe that one is much harder to get at than the front.....

    Intestinalworm likes this.
  3. sierrafery

    sierrafery Well-Known Member

    Joined:
    Jun 30, 2007
    Posts:
    14,889
    Likes Received:
    2,558
    Location:
    West of Transylvania
    That one is a nightmare with engine in situ

  4. tilly2

    tilly2 Well-Known Member

    Joined:
    Jul 28, 2019
    Posts:
    641
    Likes Received:
    216
    Location:
    Staffordshire
    You need the skills of a Gynaecologist for that one then...

  5. Interceptorxj

    Interceptorxj Well-Known Member Full Member

    Joined:
    Oct 20, 2013
    Posts:
    1,246
    Likes Received:
    876
    Location:
    Bolton, Greater Manchester.
    Cleaning the existing O ring and cap before applying a light bead of silicone sealant to the outside face of the O ring cures this leak without any need for parts to be shipped to Aus. and is a more permanent fix that won't come loose again. Contrary to others beliefs that sealant can get in the engine if you just apply the sealant to the outside edge the existing O ring prevents any sealant entering the engine side.

    jamesmartin likes this.
  6. tilly2

    tilly2 Well-Known Member

    Joined:
    Jul 28, 2019
    Posts:
    641
    Likes Received:
    216
    Location:
    Staffordshire
    Relying on silicone, and not the primary seal of the O ring, nope. I'd not use silicone on an engine, as once set, some bits could break away, enter the oil ways, and block them.

  7. Interceptorxj

    Interceptorxj Well-Known Member Full Member

    Joined:
    Oct 20, 2013
    Posts:
    1,246
    Likes Received:
    876
    Location:
    Bolton, Greater Manchester.
    The primary seal goes in first sealing the engine preventing any sealant entering the engine in any way. Totally impossible for any oil ways to get blocked.

  8. tilly2

    tilly2 Well-Known Member

    Joined:
    Jul 28, 2019
    Posts:
    641
    Likes Received:
    216
    Location:
    Staffordshire
    Yes, but in this case, the primary seal is fubared...

    Intestinalworm and sierrafery like this.
  9. Intestinalworm

    Intestinalworm Well-Known Member

    Joined:
    Nov 5, 2017
    Posts:
    589
    Likes Received:
    123
    Location:
    Australia
    The driveway is the embarrassing bit - left a "slick" at my dad's house - newish driveway!:eek::oops: Definitely is this front camshaft seal (original) - loose as can be! Never really noticed before as it's hidden behind the EGR cooler, acoustic/thermal cover and fan shroud. Suspect a small leak at the back as well as I have noticed condensed oil droplets underneath on the bell housing (?) and transmission area (not diesel, not coolant and not ATF - definitely oil). Might have to check the rocker cover seal (installed new one 12 months ago), but guess it could also be the rear camshaft seal; apparently it's nigh impossible to get to the rear seal I hear (also not regarded as a likely leak spot?).

  10. tilly2

    tilly2 Well-Known Member

    Joined:
    Jul 28, 2019
    Posts:
    641
    Likes Received:
    216
    Location:
    Staffordshire
    Best way is to get the engine steam cleaned off.... then look from where its coming from. Leave the top and rear acoustic covers off for a while...

    Intestinalworm likes this.
  11. Intestinalworm

    Intestinalworm Well-Known Member

    Joined:
    Nov 5, 2017
    Posts:
    589
    Likes Received:
    123
    Location:
    Australia
    Buying viton seal (BS330) from CBC Bearings here in Melbourne - pick-up for AUD 11.69 (includes GST) - takes a day or two for them to get it in. Will pop this on the current cap (original), smear it with a bit of clean engine oil and see how it goes. Thinking this is definitely the cheapest (and best) option.

  12. Intestinalworm

    Intestinalworm Well-Known Member

    Joined:
    Nov 5, 2017
    Posts:
    589
    Likes Received:
    123
    Location:
    Australia
    Great pic! That rear seal just looks impossible to access/replace without the engine out!? Wonder what the difference is between the front and rear camshaft seals and why it is reported that the rear seal very rarely leaks (unlike the front one)?

  13. Intestinalworm

    Intestinalworm Well-Known Member

    Joined:
    Nov 5, 2017
    Posts:
    589
    Likes Received:
    123
    Location:
    Australia
    Will add this to my list. Was always a bit wary of steam cleaning - potential damage to mechanical components (water ingress) and electrics (cooked wiring)? Worrying too much?

  14. tilly2

    tilly2 Well-Known Member

    Joined:
    Jul 28, 2019
    Posts:
    641
    Likes Received:
    216
    Location:
    Staffordshire
    Just the oily bits... I just used a can of brake cleaner, some engine cleaner, a paint brush, and a jetwash.. but it worked.

  15. Intestinalworm

    Intestinalworm Well-Known Member

    Joined:
    Nov 5, 2017
    Posts:
    589
    Likes Received:
    123
    Location:
    Australia
    Checked RAVE: Rear camshaft seal looks more like a plug (refer RAVE 12-1-6 and 12-1-7; item 20). Front camshaft seal is a plug with the o-ring (refer RAVE 12-1-6 and 12-1-7; items 31 and 32). Might explain the difference in the propensity to leak?

  16. Intestinalworm

    Intestinalworm Well-Known Member

    Joined:
    Nov 5, 2017
    Posts:
    589
    Likes Received:
    123
    Location:
    Australia
    All good - new viton seal installed re-using the original LR plastic cap. Just a smear of engine oil on the o-ring and and it went in like a treat - nice positive seal now. Picked up the BS330 viton o-ring locally for AUD 11.69. Old o-ring was squared off, hard and brittle - cracked when I removed it with the pick!

    tilly2 likes this.
  17. Intestinalworm

    Intestinalworm Well-Known Member

    Joined:
    Nov 5, 2017
    Posts:
    589
    Likes Received:
    123
    Location:
    Australia
    All good - new viton seal installed re-using the original LR plastic cap. Just a smear of engine oil on the o-ring and and it went in like a treat - nice positive seal now. Picked up the BS330 viton o-ring locally for AUD 11.69. Old o-ring was squared off, hard and brittle - cracked when I removed it with the pick!

  18. Intestinalworm

    Intestinalworm Well-Known Member

    Joined:
    Nov 5, 2017
    Posts:
    589
    Likes Received:
    123
    Location:
    Australia
    Quite a few weeks have passed now - no noticeable oil leaks now!

  19. ronsealdeath

    ronsealdeath Sagging Member

    Joined:
    Aug 30, 2012
    Posts:
    1,684
    Likes Received:
    238
    Location:
    Swansea, Wales
    A lot of mechanics use silicone or rtv sealant on that cam cover. One i spoke to reckons on some td5s its the only way to sort it. Hope yours stays fixed.

  20. sierrafery

    sierrafery Well-Known Member

    Joined:
    Jun 30, 2007
    Posts:
    14,889
    Likes Received:
    2,558
    Location:
    West of Transylvania
    :mad: IMO you should find some serious mechanics then not botchers
