ECU Swap Info

Jamiegreen · Jan 19, 2018

Hi, so if anyone followed my adventure on the what did you do disco today, I think I've come to the conclusion to sell the damaged vehicle as transport is proving too expensive. Friend listed it on a Romanian website and straight away had offers for 1000 euro plus, so cut my losses I think thats the best, might even get 1500. But.... but I have a only just 250 quid remapped ECU in there... they ain't having it!

My question is, can I go pick up a scrappy ECU from the same disco (auto) and put it in there... and are the keyfobs programed to the ECU? I have a hawkeye tool with me so could this help or does the locking system have a separate ECU... so basically is it a simple plug and play job with ECU's?..
Thanks

sierrafery · Jan 19, 2018

Not plug and play, first read the injector codes from your ECU and write them on a paper, disconnect the battery, swap ECUs reconnect the battery, go to Immobiliser - learn security code, then save the injector codes in the replacement ECU, job done, the ECU should match the vehicle's motor too so if it's 10P engine you neeed a MSB101192 or MSB101193 and if it's 15+P NNN000130 or NNN500030 the throttle tracks must be saved the same as well

Jamiegreen · Jan 19, 2018

sierrafery said:
Not plug and play, first read the injector codes from your ECU and write them on a paper, disconnect the battery, swap ECUs reconnect the battery, go to Immobiliser - learn security code, then save the injector codes in the replacement ECU, job done, the ECU should match the vehicle's motor too so if it's 10P engine you neeed a MSB101192 or MSB101193 and if it's 15+P NNN000130 or NNN500030 the throttle tracks must be saved the same as well

Think things just got a little complicated for me

Will see if the scrap company will take without ECU maybe, thanks for the info though

sierrafery · Jan 19, 2018

It's not complicated, it's about few pushes on hawkeye's buttons

Jamiegreen · Jan 19, 2018

sierrafery said:
It's not complicated, it's about few pushes on hawkeye's buttons

Hmm, I've literally never used this Hawkeye before, you wouldn't happen to know of any guides for swapping?
Thanks

sierrafery · Jan 19, 2018

no clear guide afaik... the tool's menu is quite self explanatory, select EMS-Td5 and in the programming section you find the injector codes and read, then in the Immobiliser follow the steps to learn security code

Jamiegreen · Jan 19, 2018

sierrafery said:
no clear guide afaik... the tool's menu is quite self explanatory, select EMS-Td5 and in the programming section you find the injector codes and read, then in the Immobiliser follow the steps to learn security code

cheers mate
