Discovery 2 TD5 Oil Cooler coolant outlet

Bugz · May 31, 2024

Whilst having my gearbox sorted another job is replacing the oil cooler to engine gasket.

I noticed the coolant outlet of the oil cooler is blanked off, there is the steel pipe at the back of the engine which goes to the radiator but this isn’t connected, can’t see the bottom of the radiator but guessing this has been blanked off.

Is there a reason for this?

Interceptorxj · May 31, 2024

It's a common modification and factory standard on later TD5s.

Bugz · May 31, 2024

Interceptorxj said:
It's a common modification and factory standard on later TD5s.

Hi, thanks for your reply.

Would you know the reason for this modification.

jamesDiscoTD5 · May 31, 2024

On the later TD5s it feeds the EGR cooler, so if that's been removed or blanked it doesn't do anything.
On earlier TD5s from it went to an inlet on the radiator, but LR brought out an updated radiator design where that inlet was blanked off.

Bugz · May 31, 2024

Bugz said:
Hi, thanks for your reply.

Would you know the reason for this modification.

Bugz · May 31, 2024

jamesDiscoTD5 said:
On the later TD5s it feeds the EGR cooler, so if that's been removed or blanked it doesn't do anything.
On earlier TD5s from it went to an inlet on the radiator, but LR brought out an updated radiator design where that inlet was blanked off.

Ok, thanks, was getting a bit concerned!

Bugz · May 31, 2024

Bugz said:
Ok, thanks, was getting a bit concerned!
