2012 WESTMINSTER 4.4L Diesel V8 Fuses

This site contains affiliate links for which LandyZone may be compensated if you make a purchase.

MCT65

New Member
Posts
4
Location
MARLBOROUGH
Hi
Anybody know which fuse is for the Main blower in my RR cant find it in the Handbook only says fuse number for the rear blower (didnt know i had one)!!
My RR is 2012 WESTMINSTER 4.4L Diesel V8

Last edited:
I have this for the 2011 might help although numbers dont seem to match ^^^ so not sure without actually checking against the psychical car.

J


Attachments

  • Climate control.pdf
    616.1 KB · Views: 110
Do the lights work on the heater controls or is it all dead?
Rave manual says it's a stepper motor supplied with 0v to 8v from the blower motor control

Blower
The blower is installed between the air inlets and the evaporator, and consists of 2 open hub, centrifugal fans powered by a single electric motor. Operation of the electric motor is controlled by the ATC module via the blower motor control module (voltage amplifier) installed in the outlet of the RH fan.
To produce the seven blower speeds the ATC module outputs a stepped control voltage between 0 and 8 V to the blower motor control module, which regulates a battery power feed from the central junction box (CJB) to the blower. The control voltage changes, in 1 V steps, between 2 V (blower speed 1) and 8 V (blower speed 7). If the control voltage is less than 2 V the blower is off.

Is it time yet :D
