Td4 Freelander auto no gears
- Thread starter Jonnyno1#
- Start date
This site contains affiliate links for which LandyZone may be compensated if you make a purchase.
saxavordian
Well-Known Member
- Posts
- 8,490
First welcome to the tool shed of spiders and creepy crawlies.
Second was the auto working recently and when was your last service.
Uncle Nodge will give better answer shortly.
Second was the auto working recently and when was your last service.
Uncle Nodge will give better answer shortly.
- Posts
- 15,167
- Location
- Benfleet, Essex
Its broken. Snap on isn't helping.
Yes only just bought it, needs a service was getting round to it
Nodge68
Well-Known Member
- Posts
- 32,504
- Location
- Near Newquay
That's not uncommon to see no coms with the TCM, and is likely a red herring.
First off, what does the dash show when selecting gears?
Second does the gear selector LEDs mimic what the dash is showing?
Is there a propshaft fitted to the vehicle?
- Posts
- 15,167
- Location
- Benfleet, Essex
Pssttt @Nodge68 if there isn't a single propshaft at all, it aint going nowhere (good shout mate).
Isn't the correct question is "How Many propshafts are currently fitted to the vehicle?".
Not having a lovely Freelander I can offer no further insights, so I will shut up being such a
GrumpyGel
Well-Known Member
- Posts
- 25,153
- Location
- Christchurch, New Zealand
It'll probably have 4 drive shafts to the wheels, but may have had the prop shaft(s) removed that power the back axle.Pssttt @Nodge68 if there isn't a single propshaft at all, it aint going nowhere (good shout mate).
Isn't the correct question is "How Many propshafts are currently fitted to the vehicle?".
Not having a lovely Freelander I can offer no further insights, so I will shut up being such aclever-dick.
Nodge68
Well-Known Member
- Posts
- 32,504
- Location
- Near Newquay
The question was referring to the front to back propshaft, not the 4 drive shafts.
There's an issue where the spline link to the LH front drive shaft strips, disconnecting the front wheel from the front diff.
If there's a propshaft fitted, then that will take the drive, masking the issue. However if no propshaft is fitted, then a stripped spline like, effectively disconnects the gearbox from the wheels, making have no drive.
Nodge68
Well-Known Member
- Posts
- 32,504
- Location
- Near Newquay
If the LCD and gear selector shows gear positions correctly, then it's very likely the IRD is faulty, or the spline link in the gearbox has failed.
- Posts
- 15,167
- Location
- Benfleet, Essex
Thanks. I get it.The question was referring to the front to back propshaft, not the 4 drive shafts.
There's an issue where the spline link to the LH front drive shaft strips, disconnecting the front wheel from the front diff.
If there's a propshaft fitted, then that will take the drive, masking the issue. However if no propshaft is fitted, then a stripped spline like, effectively disconnects the gearbox from the wheels, making have no drive.
GrumpyGel
Well-Known Member
- Posts
- 25,153
- Location
- Christchurch, New Zealand
I wouldn't rule the IRD out, its highly likely the culprit, but If there was noises made, I'd expect them to be when going into drive or reverse and gears/splines start rubbing/grinding against each other not when going into park.
