Notch in the steering - 04 TD5 110

Discussion in 'General Land Rover Forum' started by bankz5152, Feb 11, 2017.

  1. bankz5152

    bankz5152 Well-Known Member

    Joined:
    Jan 8, 2012
    Posts:
    6,117
    Likes Received:
    809
    Location:
    South London/North Kent
    Recently noticed that ive got a notch in my steering, but only in one point.

    Turning the wheel right from center to the 1/2 oclock position you can feel a notch, when turning from 12 - 1 the steering does feel a little light until you hit the notch then all is fine.

    No other issues notchy or otherwise in the rest of the steering, i.e full left and the rest of right.

    I disconnected the damper from the drop arm which moves freely with no notchy feeling, balljoint moves alright and is full of grease.

    New trackrods
    New balljoints
    New steering damper (TF RTC)
    Recently tracked
    No leaks from the PAS
    PAS box has enough fluid
    Steering feels normal
    No whine or other noise from the PAS

    Sprayed the column UJs with wd40, lock - lock and repeat. Then did the same with moly grease.

    Improved things a tiny bit, but still there.

    Any ideas?

  2. neilly

    neilly Well-Known Member

    Joined:
    Jan 10, 2011
    Posts:
    10,914
    Likes Received:
    3,510
    Location:
    Oxfordshireness
    Hi Bankz,

    I may have missed it . But,when you disconnected the drop arm, did the notch still happen in the steering wheel or was it OK?
    Did you isolate it to one side or the other of the drop arm?

    Cheers

  3. bankz5152

    bankz5152 Well-Known Member

    Joined:
    Jan 8, 2012
    Posts:
    6,117
    Likes Received:
    809
    Location:
    South London/North Kent
    Afternoon, The arm itself was still connected, just disconnected the damper from it. No noticeably notchyness or otherwise, reconnected notchy again.

    Once you turn past the notch steering is normal

  4. neilly

    neilly Well-Known Member

    Joined:
    Jan 10, 2011
    Posts:
    10,914
    Likes Received:
    3,510
    Location:
    Oxfordshireness
    I would isolate the steering column / Box from the track rod / steering bars etc and see where the problem appears to be residing.

    Cheers

  5. bankz5152

    bankz5152 Well-Known Member

    Joined:
    Jan 8, 2012
    Posts:
    6,117
    Likes Received:
    809
    Location:
    South London/North Kent
    As in disconnect the drop arm.ball joint from the rest of the steering system. If so so, done that and it moves freely lock to lock without issue.

  6. neilly

    neilly Well-Known Member

    Joined:
    Jan 10, 2011
    Posts:
    10,914
    Likes Received:
    3,510
    Location:
    Oxfordshireness
    When you did that, did the steering wheel still have the notch?

    Cheers

  7. bankz5152

    bankz5152 Well-Known Member

    Joined:
    Jan 8, 2012
    Posts:
    6,117
    Likes Received:
    809
    Location:
    South London/North Kent
    No, free as bird. No notches.

  8. boguing

    boguing Well-Known Member

    Joined:
    Mar 18, 2008
    Posts:
    2,291
    Likes Received:
    567
    Location:
    Dorking
    When the drop link was disconnected did you try steering it by grabbing the road wheels and twisting? (Front off the ground). In other words, I suppose, you need to keep disconnecting until you isolate it.

    Having said that - if you can employ a minion to turn the steering lock to lock and put your hands on each part of the system - you should be able to feel when you've got a mitt on the dodgy bit.

    bankz5152 and Flossie like this.
  9. bankz5152

    bankz5152 Well-Known Member

    Joined:
    Jan 8, 2012
    Posts:
    6,117
    Likes Received:
    809
    Location:
    South London/North Kent
    Good plan! Ill give that a crack tomorrow before i put me steering guard back on

    I did, I jacked up the whole front axle and moved the wheels, couldnt really feel much in it

    Last edited: Feb 11, 2017
  10. Brown

    Brown Well-Known Member

    Joined:
    Jul 11, 2012
    Posts:
    4,631
    Likes Received:
    629
    Location:
    East Midlands
    Mine used to have a notch in it. The culprit turned out to be the tapered roller bearings in the steering swivels - the ones that do duty as a 'kingpin' (although Land Rovers don't really have a kingpin as such). They'd got worn so that there were indentations where the rollers bore on the outer races. You can just about make them out in this picture:
    [​IMG]
    This was at the end of 2014. I put new ones in and they've been fine ever since.

    The notch was much more noticeable when I detached the steering linkages from the hubs and turned them by and. You could feel it as the wheels passed the straight ahead position.

    bankz5152 likes this.
  11. bankz5152

    bankz5152 Well-Known Member

    Joined:
    Jan 8, 2012
    Posts:
    6,117
    Likes Received:
    809
    Location:
    South London/North Kent
    Thanks everyone. For the time being it appears to be solved, ive worked more grease into it and all is good now. Ill save this @Brown incase it crops up again!
