Another timing issue?

Discussion in 'Introduce Yourself' started by Ian Yeates, Jun 26, 2022.

< Previous Thread | Next Thread >
  1. Ian Yeates

    Ian Yeates New Member

    Joined:
    Jun 26, 2022
    Posts:
    9
    Likes Received:
    6
    Location:
    York
    Hi, I am new to this forum, the timing or so I assume is somewhat less than desirable. The old Series 2a diesel 2.25 is smoking like a train, how I got to where I am.
    * When I bought it, about 6 weeks ago, it came with loads of receipts for the engine rebuild all machining work done last year. it started second time every time it was started, however it billowed white smoke (when cold & hot), so I thought ah! Simple injection timing issue. well I Couldn't get it, either smoking with power ( well not like the defender TD5) but some, or get rid of the smoke and no power.
    * so next I stripped the camshaft drive timing chain cover off, checked the cam/valve timing, thought great cracked it, it was a tooth out, timed the cam/valves up using DTI, and a protractor on the crankshaft. Spent some time double checking when valves opened and timing marks on the flywheel and TDC, when all double checked good reassembled it, she fired up first turn, this time black smoke, tried retiming the injector pump, couldn't get it. SO! STOP, I thought, think! Being as I had just shifted the cam round I thought it may be logical the injection drive shaft would now be out of position.
    * next out came the injection pump, and hey! The drive was out of position. So I retimed that in, now I have the injection pump back in and timed up. Primed the diesel through to the injectors, now it is a complete bugger to start, and still loads of (now) grey smoke.
    More instalment will follow,
    please feel free to comment, sympathy and advise greatfully received!
    The joys of a 50 odd year old Landy...

  2. steve2286w

    steve2286w Well-Known Member

    Joined:
    Jul 6, 2007
    Posts:
    2,734
    Likes Received:
    988
    Location:
    monkeyhangerland
    Welcome to a Landyzone
    Has it done much mileage since rebuild, are compressions all been tested , and injectors, best post this in the series section also the search is good , I think you’ll find a few other people have smoky series :D

  3. saxavordian

    saxavordian Well-Known Member

    Joined:
    Jun 8, 2015
    Posts:
    6,012
    Likes Received:
    4,926
    Location:
    outside london influence in manchester
    Welcome to landyzone eating crab apples competition.

  4. brianp38dse

    brianp38dse Well-Known Member

    Joined:
    May 13, 2014
    Posts:
    17,174
    Likes Received:
    10,673
    Location:
    heathrow
    Hello and welcome to LZ:)

  5. Ian Yeates

    Ian Yeates New Member

    Joined:
    Jun 26, 2022
    Posts:
    9
    Likes Received:
    6
    Location:
    York
    Only done few hundred miles since full engine rebuild, starting to question whether the rest of it was put together well! I've seen others not fit piston rings properly before, don' want to strip it and won't until I have checked further, I really didn't want another project but I think I have one now....
    Still no matter I am going to gave another go at the injection timing, when I get time. The injectors were high on my list of suspects so i'll whip them out and chech them too. Thanks for your reply, I wll try to figure out where the series section is and post the 2a related stuff on there later, again when I get the time

    steve2286w likes this.
  6. Ian Yeates

    Ian Yeates New Member

    Joined:
    Jun 26, 2022
    Posts:
    9
    Likes Received:
    6
    Location:
    York
    Thanks to all...

  7. ganthercage

    ganthercage Member

    Joined:
    Nov 14, 2021
    Posts:
    34
    Likes Received:
    5
    Location:
    canada
    Last edited: Jun 28, 2022
